Quick Details
-
Brand Name:
-
Cinacharm
-
Dimension(L*W*H):
-
Depend on model
-
Weight:
-
1500 KG
-
Keyword:
-
Stone Crusher
-
Color:
-
Customer Requirement
-
After sale Service:
-
7*24hours
-
Crusher type:
-
Quarry Machine Stone Crusher
-
Material:
-
Steel Material
-
Function:
-
Mining Crusher Equipment
-
Usage:
-
Crushing Work
-
Delivery Time:
-
10-15 Days
-
Quality:
-
ISO9001 CE
Quick Details
-
Application:
-
stone,ore,coal,sand
-
Capacity(t/h):
-
30-1250TPH
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Cinacharm
-
Dimension(L*W*H):
-
Depend on model
-
Weight:
-
1500 KG
-
Keyword:
-
Stone Crusher
-
Color:
-
Customer Requirement
-
After sale Service:
-
7*24hours
-
Crusher type:
-
Quarry Machine Stone Crusher
-
Material:
-
Steel Material
-
Function:
-
Mining Crusher Equipment
-
Usage:
-
Crushing Work
-
Delivery Time:
-
10-15 Days
-
Quality:
-
ISO9001 CE
Product Description
pc200*300 hammer crusher mill crushing and grinding price sell in kenya
Hammer crusher is composed of box, rotor, hammer head, counter lining plate, screen plate, etc. The grate clearance can be adjusted according to user requirements, change the size of the discharge to meet different needs of different users, with advanced structure, reliable performance, balanced work, low energy consumption advantages.
Hammer crusher can be broken materials for coal, salt, chalk, gypsum, brick, limestone, etc., also used for breaking fiber structure, elasticity and toughness of the broken wood, paper or broken asbestos cement waste to recover asbestos fiber and so on.
Product structure
WORKING PRINCIPLE
Motor drives the rotor quickly in the crushing cavity. Raw materials enter the crusher through the feeding inlet and are impacted, cut and ground by high-speed hammer heads. There is a grate under the rotor assemblly, so that materials with size smaller than the grate mesh will be screened out and others are left to be further hammered until they reach the standard size. The size of the final product can be adjusted by changing the grate, the gap between the rotor assemblly and the grate can also be adjusted according to different requirements.
Equipment Advantages
Technical Parameters
|
Model
|
Input Size (mm)
|
Output Size (mm)
|
Capacity (t/h)
|
Power (kw)
|
|
pc200x300
|
<70
|
<15
|
3-5
|
4
|
|
PC400x300
|
<100
|
<15
|
5-10
|
11
|
|
PC600x400
|
<220
|
<15
|
10-25
|
22
|
|
PC800x600
|
<350
|
<15
|
20-40
|
55
|
|
PC1000x800
|
<400
|
<15
|
25-80
|
110
|
|
PC1000x1180
|
＜650
|
<15
|
250-300
|
132x2
|
|
PC1200x1280
|
＜750
|
<15
|
300-350
|
160x2
|
|
PC1200x1590
|
＜750
|
<15
|
400-500
|
200x2
|
Wear parts supply：
We will supply the wear parts with factory price
.
Packing & Delivery
1.Standard containers.
2.Nude Packing.
3.Wooden boxes, etc
2.Nude Packing.
3.Wooden boxes, etc
