Quick Details
-
Elongation (≥ %):
-
35
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
heating element
-
Grade:
-
Ni Cu
-
Ni (Min):
-
63%
-
Model Number:
-
monel 400
-
Brand Name:
-
DZX
-
Size:
-
custom made
-
Standard:
-
ASTM B127
-
Surface:
-
Bright
-
Shape:
-
strip
-
Density:
-
8.83 G/cm3
-
Melting point:
-
1300-1390
-
Elongation:
-
35%
-
M.O.Q:
-
5 kg
-
Delivery Time:
-
7-20 Days
Quick Details
-
Resistance (μΩ.m):
-
1.5
-
Powder Or Not:
-
Not Powder
-
Ultimate Strength (≥ MPa):
-
480
-
Elongation (≥ %):
-
35
-
Place of Origin:
-
Jiangsu, China
-
Application:
-
heating element
-
Grade:
-
Ni Cu
-
Ni (Min):
-
63%
-
Model Number:
-
monel 400
-
Brand Name:
-
DZX
-
Size:
-
custom made
-
Standard:
-
ASTM B127
-
Surface:
-
Bright
-
Shape:
-
strip
-
Density:
-
8.83 G/cm3
-
Melting point:
-
1300-1390
-
Elongation:
-
35%
-
M.O.Q:
-
5 kg
-
Delivery Time:
-
7-20 Days
|
Size Range
|
|
|
|
Rod/Bar
|
8-200mm
|
|
|
Wire
|
0.15-7.5
|
|
|
Strip
|
(0.5-2.5) * (5-180)
|
|
|
Plate
|
custom made
|
|
Monel Features
Monel 400 is copper nickel alloy, has good corrosion resistance. In salty water or seawater has excellent resistance to pitting corrosion, stress corrosion ability. Especially hydrofluoric acid resistance and resistance to the hydrochloric acid. Widely used in the chemical, oil, Marine industry.
It is widely used on many aspects,like valve and pump parts, electronic components, chemical processing equipment, gasoline and freshwater tanks, petroleum processing equipment, propeller shafts, marine fixtures and fasteners,boiler feedwater heaters and other heat exchangers.|
Item
|
Ni%
|
Cu%
|
Fe%
|
Mn%
|
C%
|
Si%
|
S%
|
|
Monel 400
|
Min 63
|
28-34
|
Max 2.5
|
Max 2.0
|
Max 0.3
|
Max 0.5
|
Max 0.024
|
|
Item
|
Density
|
Melting point
|
Tensile Strength (RmN/mm2)
|
Yield Strength (RP0.2N/mm2)
|
Elongation (A5 %)
|
HB
|
|
Monel 400
|
8.83 g/cm3
|
1300-1390℃
|
480
|
170
|
35%
|
≥331
|
|
Monel 400
|
Bar/Rod
|
Forging
|
Pipe
|
Sheet/Strip
|
Welding Wire
|
|
Standard
|
ASTM B164
|
ASTM B564
|
ASTM B165
|
ASTM B127
|
ERNiCu-7
|
