Quick Details
-
Brand Name:
-
BD
-
Model Number:
-
ZC3-A
-
Product name:
-
Schmidt Rebound Hammer
-
Standard Impact energy:
-
2.207J
-
Testing Range:
-
10~60Mpa
-
Stroke of rebound hammer:
-
75mm
-
Average rebound value:
-
80±2mm
-
Stiffness of pullback spring:
-
7.84N/cm
-
Friction of pointer slider:
-
0.5N~0.8N
-
Single package size::
-
35X12X22 cm
-
weight:
-
2.21kg
Quick Details
-
Warranty:
-
1 Year
-
Power:
-
Hydraulic
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
BD
-
Model Number:
-
ZC3-A
-
Product name:
-
Schmidt Rebound Hammer
-
Standard Impact energy:
-
2.207J
-
Testing Range:
-
10~60Mpa
-
Stroke of rebound hammer:
-
75mm
-
Average rebound value:
-
80±2mm
-
Stiffness of pullback spring:
-
7.84N/cm
-
Friction of pointer slider:
-
0.5N~0.8N
-
Single package size::
-
35X12X22 cm
-
weight:
-
2.21kg
Product Description
Produict Details
ZC3-A concrete test hammer can accurately measure the thickness of the protective layer of the steel bar determine the position, orientation and distribution of the steel bar, measure the protective layer of the steel bar and estimate the diameter of the steel bar, store, view and transmit the monitoring data. This instrument can be widely used in real estate, highway bridges, engineering construction. Supervision and other areas of urban construction.
Standard: JGJ/T23-2011; GB /T9138-1988; JJG817-93; ASTM C 805; BS 1881:202; NF P18-417; DIN 1048; UNI 9189
Standard: JGJ/T23-2011; GB /T9138-1988; JJG817-93; ASTM C 805; BS 1881:202; NF P18-417; DIN 1048; UNI 9189
Specification
|
Product Name
|
Mechnical Hammer
|
|
The static friction of pointer slider
|
0.65N±0.15N
|
|
Length of spring stretch
|
75±0.3mm
|
|
Average rebound hammer on steel anvil
|
80±2
|
|
Measuring Range
|
10~60Mpa
|
|
Radius of spherical tip
|
25mm±1mm
|
|
Working Temperature
|
-10℃~+50℃
|
|
Working Humidity
|
≤90%RH
|
|
Dimensions
|
Ф54x280mm
|
|
Gross Weight
|
2.1kg
|
Application
a. Package: Each product is individually packaged, providing instructions for chargers etc.
b. Security: No nuclear radiation and waste gas pollution, safe operation and use, environmental protection.
c. Operation: Simple operation, fast test speed, detection point only 35 seconds.
If you have any questions, please contact me without hesitation, welcome your inquiry! Price can be negotiated!
