Quick Details
-
Fork Length:
-
0
-
Fork Width:
-
0
-
Overall Dimensions:
-
6850*4120*4326mm
-
Weight (KG):
-
9000 kg
-
standard configuration:
-
air conditioner, side shift
-
Wheelbase:
-
4520mm
-
Turning radius:
-
6300mm
-
Transmission type:
-
Auto-shift / Interlock
-
Rated power:
-
164KW
-
Tyres:
-
Pneumatic
-
Cylinder number:
-
6
-
Gear number:
-
3 F / 3 R
-
Certification:
-
CE/ISO
-
Marketing Type:
-
Other
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
LTMG
-
Fork Length:
-
0
-
Fork Width:
-
0
-
Overall Dimensions:
-
6850*4120*4326mm
-
Weight (KG):
-
9000 kg
-
standard configuration:
-
air conditioner, side shift
-
Wheelbase:
-
4520mm
-
Turning radius:
-
6300mm
-
Transmission type:
-
Auto-shift / Interlock
-
Rated power:
-
164KW
-
Tyres:
-
Pneumatic
-
Cylinder number:
-
6
-
Gear number:
-
3 F / 3 R
-
Certification:
-
CE/ISO
-
Marketing Type:
-
Other
Product Description
Specification
|
PERFORMANCES
|
|
|
|
|||
|
|
|
|
|
|||
|
Load capacity
|
Kg
|
9000
|
8000
|
|||
|
Maximum stacking layer
|
|
8
|
7
|
|||
|
Lift speed, laden/unladen
|
m/s
|
0.55 / 0.60
|
0.55 / 0.60
|
|||
|
Lowering speed, laden/unladen
|
m/s
|
0.60 / 0.60
|
0.60 / 0.60
|
|||
|
Travel speed, laden/unladen
|
km/h
|
26 / 28
|
25 / 27
|
|||
|
Climbing ability, laden/unladen
|
%
|
38 / —
|
30 / —
|
|||
|
Tractive force
|
kN
|
157.5
|
107.5
|
|||
|
DIMENSIONS
|
|
|
|
|||
|
Wheelbase
|
y(mm)
|
4520
|
4020
|
|||
|
Height of mast, lowered
|
h1(mm)
|
12399
|
11091
|
|||
|
Lift height
|
h3(mm)
|
21400
|
16352
|
|||
|
Tilt angle (forward / backward)
|
α/β( / °)
|
3 / 4
|
3 / 4
|
|||
|
Height of mast, extended
|
h4(mm)
|
21818
|
19204
|
|||
|
Height of cabin
|
h6(mm)
|
4326
|
4326
|
|||
|
Height, operator's seat
|
h7(mm)
|
3226
|
3206
|
|||
|
Twistlock height, lowered
|
h13(mm)
|
2290
|
2290
|
|||
|
Maximum twistlock height
|
h3+h13(mm)
|
21216
|
18600
|
|||
|
Overall length
|
l1(mm)
|
6850
|
6450
|
|||
|
Length to spreader face
|
l2(mm)
|
6682
|
6277
|
|||
|
Overall width
|
b1/b2(mm)
|
4120 / 2570
|
3627 / 2398
|
|||
|
Width of spreader 20'/40'
|
b3(mm)
|
6050 / 12150
|
6050 / 12150
|
|||
|
Turning radius
|
Wa(mm)
|
6300
|
5700
|
|||
|
Wheelspan, Front wheels
|
b10(mm)
|
3280
|
2880
|
|||
|
Wheelspan, Rear wheels
|
b11(mm)
|
2171
|
2068
|
|||
|
ENGINE
|
|
|
|
|||
|
Model
|
|
CH90
|
CH80
|
|||
|
Engine manufacturer / type
|
|
Cum&mins / QSB6.7
|
Cum&mins / QSB6.7
|
|||
|
Cylinder number / displacement
|
|
6 / 6700 cm3
|
6 / 6700 cm3
|
|||
|
Rated power
|
|
164Kw @ 2200 rpm
|
129Kw @ 2200 rpm
|
|||
|
Maximum torque
|
|
949NM @ 1500 rpm
|
800NM @ 1500 rpm
|
|||
|
Rated current of alternator
|
|
100 A
|
70 A
|
|||
|
Battery
|
|
24 V (2 x 12 /110)
|
24 V (2 x 12 /110)
|
|||
|
TRANSMISSION
|
|
|
|
|||
|
Model
|
|
CH90
|
CH80
|
|||
|
Manufacturer / type
|
|
ZF/3WG211 AUTO
|
ZF/3WG211 AUTO
|
|||
|
Clutch - type
|
|
Torque Converter
|
Torque Converter
|
|||
|
Transmission
|
|
Auto-shift/ Interlock
|
Auto-shift / Interlock
|
|||
|
Gear number
|
|
3 F / 3 R
|
3 F / 3 R
|
|||
|
BRAKE SYSTEM
|
|
|
|
|||
|
Service brake: Wet-disc
|
|
|
|
|||
|
Parking brake: Brake enabled when power of
|
|
|
|
|||
|
DRIVE AXLE
|
|
|
|
|||
|
Model
|
|
CH90
|
CH80
|
|||
|
Driver axle manufacturer
|
|
KESSLER / Germany
|
KESSLER / Germany
|
|||
|
Type
|
|
D81PL488 - NLB
|
D81PL478 - NLB
|
|||
|
STEER AXLE
|
|
|
|
|||
|
Model
|
|
CH90
|
CH80
|
|||
|
Steering axle Manufacturer
|
|
OMCI / Italy
|
OMCI / Italy
|
|||
|
Type
|
|
ASF
|
Z16A1
|
|||
|
Steering type-Single cylinder
|
|
Double action cylinder
|
Double action cylinder
|
|||
|
TYRES
|
|
|
|
|||
|
Drive wheels
|
|
14.00－24 28PR
|
12.00－24 24PR
|
|||
|
Steering wheels
|
|
14.00－24 28PR
|
12.00－24 24PR
|
|||
|
Type
|
|
Pneumatic tyre
|
Pneumatic tyre
|
|||
|
Pressure
|
|
10 bar
|
10 bar
|
|||
|
Quantity, Front / Rear
|
|
4 / 2
|
4 / 2
|
|||
