Luxurious and comfortable cabin
* Air conditioner and sunroof window
* Build-design to prevent dust from entering inside the cabin
* Doors opening wide for easy entry and exit
* Adjustable steering wheel
* Standard AM/FM/USB/AUX radio
* Sun visor
- Product Details
- {{item.text}}
Quick Details
-
Engine Brand:
-
Laidong
-
Weight:
-
2165 KG
-
Job requirements 1:
-
Rotary tillage
-
Job requirements 2:
-
sowing
-
Job requirements 3:
-
orchard
-
Job requirements 4:
-
hills
-
Job requirements 5:
-
Plant protection
-
Job requirements 6:
-
Small plot operations
-
Advantage1:
-
High driving comfort
-
Advantage2:
-
The skin is durable
-
Advantage3:
-
Good reliability
-
Advantage4:
-
Strong applicability
Quick Details
-
Brand Name:
-
LOVOL
-
Place of Origin:
-
Jiangsu, China
-
Marketing Type:
-
New Product 2022
-
Engine Brand:
-
Laidong
-
Weight:
-
2165 KG
-
Job requirements 1:
-
Rotary tillage
-
Job requirements 2:
-
sowing
-
Job requirements 3:
-
orchard
-
Job requirements 4:
-
hills
-
Job requirements 5:
-
Plant protection
-
Job requirements 6:
-
Small plot operations
-
Advantage1:
-
High driving comfort
-
Advantage2:
-
The skin is durable
-
Advantage3:
-
Good reliability
-
Advantage4:
-
Strong applicability
Product Description
Detailed parameters
|
MODEL
|
|
UNIT
|
TD1204
|
|
|
IMENSIONS OF TRACTOR
|
TYPE
|
/
|
DRIVE TYPE (4x4)
|
|
|
|
kW
|
kW
|
88.2
|
|
|
|
DIMENSION (LxWxH)
|
mm
|
4535x2100x3060
|
|
|
|
WHEEL BASE
|
mm
|
2385
|
|
|
|
MIN.GROUND CLEARANCE
|
mm
|
420
|
|
|
|
WEIGHT
|
kg
|
4560
|
|
|
|
TREAD
|
mm
|
FRONT TREAD:1620(1620 ~ 1970)ADJUSTABLE REAR TREAD:1620(1620 ~ 1950)ADJUSTABLE
|
|
|
MATCHED POWER
|
CLUTH TYPE
|
/
|
DRY-TYPE,DOUBLE-ACTING
|
|
|
|
ENGINE
|
/
|
YUNNEI 4 CYLINDER
|
|
|
|
RATED SPEED
|
r/min
|
2300
|
|
|
WORKING PORTING
|
GEAR
|
/
|
16F+8R
|
|
|
|
PTO TYPE
|
/
|
8 PIN、①38、ITYPE(OPTION: 21 PIN)
|
|
|
|
PTO RATED POWER
|
kW
|
>75
|
|
|
|
PTO SPEED
|
r/min
|
760/1000、760/850
|
|
|
HYDRUALIC SYSTEM
|
THREE POINT LINKAGE
|
/
|
REAR, THREE-POINT SUSPENSION ,CAT2
|
|
|
|
HYDRUALIC OUTPUT
|
/
|
2-WAY VALVE
|
|
|
|
HYDRUALIC ADJUSTMENT MODE
|
/
|
FORCED HYDRUALIC SIYSTEM, POSITION CONTROL ,FLOATING CONTROL
|
|
|
|
MAX.LIFTING FORCE AT FRAME CENTER
|
kN
|
>21.2
|
|
|
TYRE TYPE
|
NORM TYRE SIZE (FRONT/TEAR)
|
/
|
13.6-24/16.9-38
|
|
|
|
OPTIONAL TYRE (I)
|
/
|
12.4-24/16.9-34
|
|
|
OTHER OPTIONS
|
WARM CABIN
|
/
|
OPTIONAL
|
|
|
|
AIR CABIN
|
/
|
OPTIONAL
|
|
Details Images
Robust and reliable engine
* 3-or 4-cylinder engine
* Synchronized gearbox for smoother operation
* High torque engine designed for reliability and power
* Rigid, high-strength cylinders to perform the most labour-intensive tasks
* High torque reserve
* High pressure lubrication system
* 3-or 4-cylinder engine
* Synchronized gearbox for smoother operation
* High torque engine designed for reliability and power
* Rigid, high-strength cylinders to perform the most labour-intensive tasks
* High torque reserve
* High pressure lubrication system
All our models are also offered without cab
TRACTORS SPECIFICATIONS
8+8 or 12+12 synchronized gearbox
Reliable,high performance front axle
Strong, durable rear axle
Strong, durable rear axle
Ergonomic interior cabin
Proven Doosan engine
READY FOR ALL TYPES OF WORKS
