Quick Details
-
Place of Origin:
-
Taiwan, China
-
Brand Name:
-
SHYUAN YA
-
Model Number:
-
BA250-112T-2C
-
Voltage:
-
115, 230V
-
Air Flow:
-
945 ~ 1024 CFM
-
Impeller:
-
Plastic PA
-
Motor:
-
External Rotor Motor
-
Rotor:
-
Black Paint
-
Bearing:
-
Dual Ball Bearing
-
Lead Wire:
-
450mm AWG# 20
-
Insulation:
-
Class "B" or "F"
-
Safety:
-
Thermally Protected (Auto Restart)
-
Operating Temperature:
-
-20°C to +60°C
Quick Details
-
Applicable Industries:
-
Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Home Use, Retail
-
Electric Current Type:
-
AC
-
After-sales Service Provided:
-
Online support
-
Place of Origin:
-
Taiwan, China
-
Brand Name:
-
SHYUAN YA
-
Model Number:
-
BA250-112T-2C
-
Voltage:
-
115, 230V
-
Air Flow:
-
945 ~ 1024 CFM
-
Impeller:
-
Plastic PA
-
Motor:
-
External Rotor Motor
-
Rotor:
-
Black Paint
-
Bearing:
-
Dual Ball Bearing
-
Lead Wire:
-
450mm AWG# 20
-
Insulation:
-
Class "B" or "F"
-
Safety:
-
Thermally Protected (Auto Restart)
-
Operating Temperature:
-
-20°C to +60°C
|
Specification
|
|
|
|
Air Flow
|
945 ~ 1024 CFM
|
|
|
Impeller
|
Plastic PA
|
|
|
Motor
|
External Rotor Motor
|
|
|
Rotor
|
Black Paint
|
|
|
Bearing
|
Dual Ball Bearing
|
|
|
Lead Wire
|
450mm AWG# 20
|
|
|
Insulation
|
Class “B” or “F”
|
|
|
Safety
|
Thermally Protected (Auto Restart)
|
|
|
Operating Temperature
|
-20°C to +60°C
|
|
|
Weight
|
2700g
|
|
Related Products
|
Product Name
|
|||||
|
Air Flow
|
234 ~ 273 CFM
|
280~315CFM
|
287 ~ 331 CFM
|
||
|
Impeller
|
Plastic PA (Polyamide Glass-fiber Reinforced)
|
|
|
||
|
Motor
|
Capacitor-Run Induction and External Rotor Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to +70°C
|
|
|
||
|
Product Name
|
|||||
|
Air Flow
|
348 ~ 389 CFM
|
371 ~ 421 CFM
|
229 ~267CFM
|
||
|
Impeller
|
Plastic PA (Polyamide Glass-fiber Reinforced)
|
|
|
||
|
Motor
|
Capacitor-Run Induction and External Rotor Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to +70°C
|
|
|
||
|
Product Name
|
|||||
|
Air Flow
|
387 ~ 426 CFM
|
339 ~ 378 CFM
|
229 ~267CFM
|
||
|
Impeller
|
Plastic PA (Polyamide Glass-fiber Reinforced)
|
|
|
||
|
Motor
|
Capacitor-Run Induction and External Rotor Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to +70°C
|
|
|
||
|
Product Name
|
|||||
|
Air Flow
|
410 ~ 451 CFM
|
482 ~ 590 CFM
|
460 ~ 527 CFM
|
||
|
Impeller
|
Plastic PA (Polyamide Glass-fiber Reinforced)
|
|
|
||
|
Motor
|
Capacitor-Run Induction and External Rotor Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to +70°C
|
|
-20°C to +60°C
|
||
|
Product Name
|
|||||
|
Air Flow
|
586 ~ 669 CFM
|
682 ~ 772 CFM
|
711 ~ 807 CFM
|
||
|
Impeller
|
Plastic PA (Polyamide Glass-fiber Reinforced)
|
|
|
||
|
Motor
|
Capacitor-Run Induction and External Rotor Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to +60°C
|
|
-20°C to +60°C
|
||
|
Product Name
|
|||||
|
Air Flow
|
700 ~ 774 CFM
|
824 ~ 909 CFM
|
945 ~ 1024 CFM
|
||
|
Impeller
|
Plastic PA (Polyamide Glass-fiber Reinforced)
|
|
|
||
|
Motor
|
Capacitor-Run Induction and External Rotor Motor
|
|
|
||
|
Insulation
|
Class “B” or “F”
|
|
|
||
|
Operating Voltage Range
|
85VAC to 125VAC for 115V Type / 185VAC to 245VAC for 230V Type
|
|
|
||
|
Operating Temperature
|
-20°C to +60°C
|
|
-20°C to +60°C
|
||
Questions & Answers
Q: What information do you need to provide in order to get a quotation?
A: Generally, information about Size,Air Flow,Voltage of required fans
is needed in order to select a right fan for you and provide you a quotation.
Q: Can I have samples for testing before ordering products?
A: Yes, we sincerely suggest that customers should have some samples
of required fans for testing because the truly performance of fans can be
fully demonstrated after testing is conducted.
Q: Can I have a discount for the quoted price?
A: The quoted price is based on annual usage quantity. If annual usage
quantities increase, please provide the information to our sales.
We will provide you a further discount.
Q: What is the warranty of products?
A: All of our products have 1 year warranty. Every product has its own
production code. This code is able to track the production time.
Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we accept OEM orders.
