- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shanxi, China
-
Brand Name:
-
HIG
-
Model Number:
-
hig-280
-
Standard:
-
BS,DIN,ANSI
-
Temperature:
-
-20 ~ 120°c
-
Model:
-
Half coupling/socket, full coupling/socket
-
Surface:
-
Galvanized,Electro galvanised,Normal black/Shining black
-
Certificate:
-
ISO9001:2000,BV
-
Material:
-
Steel
-
Thread:
-
BSPP BSPT NPT
-
Packing:
-
Wooden Case
-
MOQ:
-
1000pcs
Quick Details
-
Technics:
-
casting,forged
-
Shape:
-
Equal
-
Head Code:
-
round
-
Place of Origin:
-
Shanxi, China
-
Brand Name:
-
HIG
-
Model Number:
-
hig-280
-
Standard:
-
BS,DIN,ANSI
-
Temperature:
-
-20 ~ 120°c
-
Model:
-
Half coupling/socket, full coupling/socket
-
Surface:
-
Galvanized,Electro galvanised,Normal black/Shining black
-
Certificate:
-
ISO9001:2000,BV
-
Material:
-
Steel
-
Thread:
-
BSPP BSPT NPT
-
Packing:
-
Wooden Case
-
MOQ:
-
1000pcs
| STEEL MERCHANT COUPLING/SOCKET DETAILS | ||
| Material | Carbon steel A105 /20# | |
| British Standard | Threads:BS21 | |
| DIN standard | Threads: DIN2999 | |
| American Standard | Threads:ASTM A865-9 /ISO 7/1 | |
| Hydraulic Test | Working Pressure: Max 1.5MPa | |
| Test Pressure: Max 2.5MPa | ||
| Temperature: | -20 ~ 120°c | |
| Model | Half coupling/socket, full coupling/socket | |
| Surface | ØGalvanized | |
| ØElectro galvanised ØNormal black/Shining black | ||
| Size | OD | 1/8-8" |
| Wall Thickness | 0.5mm-10mm | |
| SCH20,SCH30,SCH40,SCH80,SCH100.SCH120,SCH160,STD,XS,XXS,CLASS A, CLASS B, CLASS C, etc. | ||
| Length | Less than 12m or as buyer's requirements | |
| Series | Heavy series, Standard series, Medium series, Light series | |
| Connection | Female | |
| Shape | Equal | |
| Certificate | ISO9001:2000,BV | |
| Application | fittings are widely used connected to the pipes with water,oil ,gas and so on. | |
| Related products | 1. Flanges | 2. Malleable iron pipe fittings |
| 3. Pipes | 4. Carbon steel butt-welding fittings | |
| 5. Valves | 6. High-pressure fittings | |
| 7. Brass fittings | 8. P.T.F.E .thread seal tape | |
| 9. Copper fittings | 10. Ductile iron pipe fittings | |
| 11. Grooved fittings | 12. Sanitary fittings, etc,. | |
| Customers’ drawings or designs are available. | ||
| Package | 1. Cartons Without Pallets. | |
| 2. Cartons With Pallets. | ||
| 3. Double Woven Bags | ||
| Or as buyer’s requirements. | ||
| Delivery detail | According to the quantities and specifications of each order. | |
| Normal delivery time is from 30 to 45 days after receiving the deposit. | ||
