Quick Details
-
Brand Name:
-
ONV , OEM/ODM accepted
-
Model Number:
-
ONV-H1064PLS
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
6-Port 10/100Mbps PoE Switch
-
POE port:
-
Port 1 to 4 IEEE802.3af/at @POE
-
PoE Standard:
-
IEEE802.3af/at
-
Forwarding Mode:
-
Store and Forward(Full Wire Speed)
-
MAC Address Table:
-
1K
-
Buffer Memory:
-
768k
-
Max Power Per Port:
-
30W
-
Total PWR / Input Voltage:
-
65W(DC52V)
-
Operation TEMP / Humidity:
-
-20~+55°C;5%~90% RH Non condensing
-
Warranty:
-
1 year, lifelong maintenance.
-
Certification:
-
FCC, ce, RECH, RoHS, CE RoHS FCC
Quick Details
-
Transmission Rate:
-
10/100Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
1.6
-
Brand Name:
-
ONV , OEM/ODM accepted
-
Model Number:
-
ONV-H1064PLS
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
6-Port 10/100Mbps PoE Switch
-
POE port:
-
Port 1 to 4 IEEE802.3af/at @POE
-
PoE Standard:
-
IEEE802.3af/at
-
Forwarding Mode:
-
Store and Forward(Full Wire Speed)
-
MAC Address Table:
-
1K
-
Buffer Memory:
-
768k
-
Max Power Per Port:
-
30W
-
Total PWR / Input Voltage:
-
65W(DC52V)
-
Operation TEMP / Humidity:
-
-20~+55°C;5%~90% RH Non condensing
-
Warranty:
-
1 year, lifelong maintenance.
-
Certification:
-
FCC, ce, RECH, RoHS, CE RoHS FCC
6-Port 10/100Mbps PoE Switch
The ONV-H1064PLS is a 10/100Mbps unmanaged PoE switch independently developed by ONV . it has 4 *10/100M PoE ports and 2*10/100M uplink RJ45 ports, Port 1- 4 can support IEEE802.3af/at standard PoE power supply, single port PoE power up to 30W, and the maximum POE output power is 65 W .
Technical Specification:
ORDERING INFORMATION
|
Model |
Description |
|
ONV- H1064PL S |
Unmanaged PoE switch with 4* 10/100M PoE ports and 2* 10/100M uplink RJ45 ports. Port 1-4 can support IEEE802.3af/at PoE Standard. Adjust function switch, Port 1-4 can support 10M/250m long distance transmission. Built-in 65W power supply . |
|
ONV-H1108PLS |
Unmanaged PoE switch with 8* 10/100M PoE ports and 2* 10/100M uplink RJ45 ports. Port 1-8 can support IEEE802.3af/at PoE Standard. Adjust function switch, Port 1-8 can support 10M/250m long distance transmission. Built-in 1 0 0W power supply . |
|
Note: The PoE switches series does not match the hanging ear by default. If you need it, you need to purchase it separately! |
|
Dimension:
Application:
FAQ
1. Why choose us?
We are the first manufacturer in Shenzhen China to produce intelligent PoE Switch ,PoE injector ,PoE splitter,etc.Our chips are of American military-grade with high stability and high performance.We have our own R&D team as well.
2.What about the after sales service?
We offer all solutions to all our products after selling.
3. Are you manufacturer?
Yes ,we have our own factory which floor area is 5000m2 and have 8 offices in China.
4.What's the application of your POE products?
That can fit all the IP camera ,IP telephone,or other devices ,and non IP products as well .
