Quick Details
-
Size:
-
---, 16000x2500x1710mm
-
Place of Origin:
-
Tianjin, China
-
Name:
-
roll mafi trailer
-
Applacation:
-
for Transportation
-
Finish:
-
Shop primer & painted
-
Color & logo:
-
As your requirements
-
Tare:
-
11.5T
-
Steel plate:
-
5mm checker
-
Certification:
-
DOT
Quick Details
-
Type:
-
Travel Trailer
-
Max Payload:
-
30Ton
-
Brand Name:
-
LTI
-
Size:
-
---, 16000x2500x1710mm
-
Place of Origin:
-
Tianjin, China
-
Name:
-
roll mafi trailer
-
Applacation:
-
for Transportation
-
Finish:
-
Shop primer & painted
-
Color & logo:
-
As your requirements
-
Tare:
-
11.5T
-
Steel plate:
-
5mm checker
-
Certification:
-
DOT
Hot Sale Products
Product Description
16m two Bridges Bridge Plate Spring High and Low Plate for Semi Trailer
Technical requirements.
2、Self-weight of about 11.5t (frame net weight of about 9.3t), load 30t Cargo platform on both sides of the illustrated position each installed 1 tool box
The vehicle size 16000x2500x1710mm Selected in line with the national 3C standard lamps, voltage 24V
The height of the direction of the size of the theoretical data, the actual situation will have deviations, the whole car laying 3mm patterned steel plate
The actual production height shall prevail
4、The front section of the cargo platform is 6m in area and can be spliced to meet the standard of 40 feet after disassembling and loading.
3、Select domestic 13t axle, automatic adjusting arm, 1, 2 axle with ABS. Container transportation requirements
Choose two axles positively mounted leaf spring suspension, suitable for 7 leaf springs 90x16mm Choose 12R22.5 tires, suitable for 9.0-22.5 iron steel rims.
5、This is a preliminary plan, the specific content of the actual confirmation of the production drawings shall prevail.
The front end of the platform uses 28t linkage mechanical legs.
Specification
|
Name
|
12.4-meter two-axle flatbed truck (8-lock)
|
Qty
|
1pc
|
|
|
||
|
Hanging:
|
2-axis 7-leaf spring
|
|
|
|
|
||
|
Number of axles and models
|
Luyue 13T axle/two 1820
Manual adjusting arm
|
Support
device
|
TSU28T Linkage
|
traction pin
|
90# Assembly
|
||
|
Number of
steel plate springs
|
7
|
brake
sub-compact
|
Dual Axis
Energy Storage
|
throttle
|
China Brand
|
||
|
Specification and quantity of steel ring
|
9.0-22.5， 9pcs China brand
|
Color
|
Red
|
Tool box
|
1 pc
|
||
|
Tire Model and Quantity
|
12R22.5，China brand；9 pcs
|
|
|
spare tire
carrier |
1 pc
|
||
