Quick Details
-
Power:
-
1.1kw or Customized
-
Dimension(L*W*H):
-
2000*1100*1900mm or customized
-
Weight (KG):
-
400
-
product type::
-
Sand grit blasting room / sand blasting booth
-
Application::
-
Abrasive Blast Rust Cleaning
-
Usage::
-
Stripping Surface Cleaning
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CLEAR
-
Marketing Type:
-
New Product
-
Power:
-
1.1kw or Customized
-
Dimension(L*W*H):
-
2000*1100*1900mm or customized
-
Weight (KG):
-
400
-
product type::
-
Sand grit blasting room / sand blasting booth
-
Application::
-
Abrasive Blast Rust Cleaning
-
Usage::
-
Stripping Surface Cleaning
Product Description
Sand blasting device
This shot blasting machine is equipped with 1 sand blasting device, a total of 2 spray guns, blasting efficiency > 28 m2/h (including auxiliary time), nozzle reliable wear resistance, hardness >55HRC.
Protective masks
It uses electric control and gas control combined control mode, high degree of automation.With 24 v safety voltage, to ensure the safety of operators.
Pulse jet type cartridge filter
The wind speed of the pipeline and branch pipes of the system shall not be lower than 18 m/s. The two-level dust removal mode of the inertial dust collector and the back-blowing bag dust collector with pulse is adopted.It is composed of dust collector, dust collector, air valve, dust collector, fan, etc.Dust removal efficiency≥99.5% .
Specification
|
Outside Size
|
1200mm X2950*4350mm (L*W*H)
|
|
Inside Size
|
1000mm X2950*4000mm (L*W*H)
|
|
Wall panel and body
|
Made of 3.2T iron plate, 6.0T rubber,48*100*5.0T U-steel,all steel grating floor,H-steel
|
|
Continuous type Sand blaster
|
Quantity of gun：2 pieces
Working air pressure：0.5-0.7MP
Volume： 0.8m³
Abrasive flow：(3600- 4400)kg/h
|
|
Elevator
|
Lifting capacity：15t/h ,
|
|
Separator
|
Separation capacity：15t/h
|
|
Vertical scraper conveyer
|
Conveying capacity：15t/h pneumatic
|
|
Horizontal scraper conveyer
|
Conveying capacity：15t/h pneumatic
|
|
Load flat wagon
|
Load capacity：5T
Running power:3kw
|
|
Floodlight
|
≥300LUX，explosion-proof lights
|
|
Ventilation quantity
|
14500m³/h
|
|
Duster collector
|
Made of 3.2T iron plate,including 18kw fan, chimney,pipe,pusle shaking system
|
|
Electric and control system
|
Pulse valve,wire,electric control unit
|
|
|
|
Related Products
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
After Sales Service
Free parts within 1 year warranty
Life long technical support and after sale service
