Diesel Engine
|
|
|
|
Engine model
|
4BTA3.9-GM47
|
|
|
Engine manufacturer
|
Cummins
|
|
|
Number of Cylinders
|
4 cylinders in line
|
|
|
Cycle
|
4 stroke
|
|
|
Aspiration
|
Turbocharged & Aftercooled
|
|
|
Bore×Stroke
|
102mm x 102mm
|
|
|
Displacement
|
3.9L
|
|
|
Output Power
|
47KW
|
|
|
Governor
|
Electronic
|
|
|
100% Prime power fuel Consumption
|
213g/kw.h
|
|
|
Cooling System
|
Sea water pump & heat exchanger
|
|
|
Starter Motor
|
DC24V
|
|
|
Alternator
|
DC24V
|
|
|
Alternator
|
|
|
|
Alternator Model
|
Stamford/Marathon
|
|
|
Prime power
|
40KW
|
|
|
Frequency/speed
|
50HZ/1500rpm
|
|
|
Exciter type
|
Single bearing, Brushless, Self-excited
|
|
|
Power factor
|
0.8
|
|
|
Voltage adjust range
|
≥5%
|
|
|
Voltage regulation NL-FL
|
≤±1%
|
|
|
Insulation Grade
|
H
|
|
|
Protection Grade
|
IP23
|
|
|
Phase
|
Three phases
|
|
|
Rated power
|
Engine
|
Alternator
|
Control panel
|
|
20 kw~1300kw
|
Cummins
|
Stamford
Leroy somer Marathon Mecc alte ABB Chinese alternators |
Deepsea
ComAp Harsen Smartgen |
|
8kw~1600kw
|
Perkins
|
|
|
|
68kw~504kw
|
Volvo
|
|
|
|
20 kw~500kw
|
Deutz
|
|
|
|
220 kw-2400kw
|
MTU
|
|
|
|
280kw-800kw
|
MAN
|
|
|
|
600kw-1800kw
|
Mitsubishi
|
|
|
|
50kw-650kw
|
Doosan
|
|
|
|
2kw~2500kw
|
Chinese engine
|
|
|
|
Engine
|
Fuel System
|
Cooling system
|
Exhaust system
|
|||
|
Coolant Heater
Lube oil heater Electronic governor Engine oil temperature |
External Tank
Water Separator |
50-60 Radiator,
Remote radiator Cooling tower |
Heavy Duty air filter
Silencer Enclosures |
|||
|
Alternator
|
Control System
|
Others
|
Voltage Connections
|
|||
|
Anti Condensation
Heater Permanent Magnet Generator-PMG Drop CT-for paralleling |
Remote Control Panel
Auto Transfer Switch ATS-Control Panel Paralleling System Electricity Output Cabinet |
Rainproof Type
Soundproof Type Containerized Type Trailer Type Spare Parts |
480/277V
440/254V 416/240V 400/230V 380/220V 240/139V 220/127V 208/120V |
|||
|
High Voltage of 6.3kv, 6.6kv, 10.5kv, 13.8kv etc are available
|
|
|
|
|||
