Quick Details
-
Brand Name:
-
RGW
-
Model Number:
-
RGW-Z1806
Quick Details
-
Warranty:
-
3 years
-
After-sale Service:
-
Online technical support
-
Place of Origin:
-
China
-
Brand Name:
-
RGW
-
Model Number:
-
RGW-Z1806
10.4 inch high resolution LCD screen,
Menu operation Language: Chinese/English.
Double probe sockets:
A mode probe: 10MHz, imported probe with fixation light.
B mode probe: 10MHz, imported transducer.
Display mode
: B, B/B, 4B, B/A, A
Gains range: 0--120dB.
Dynamic range: 30-100dB, visual and adjustable.
Gray: 256.
Intelligent TGC adjustment: 8 segments.
Build-in D disk: 4GB, save mass data, images, reports, etc.
Report function: print screen, IOL report, case report with picture, etc.
A scan
Resolution: 0.01mm
Gain adjustable: 0-120dB
Measurement range: 12-43mm(1640m/s)
Accuracy: ±0.02mm
Measuring parameter: ACD, LENS, body Length, axial length.
Eye mode: normal/aphakia/dense cataract/PMMA, Acrylic & Silicon for Pseudo Phakic eyes
Measuring Mode: Contact and Immersion, automatic and manual.
Measurement methods: A single-point measurement(under A mode); five-point measurement(under A mode).
Calculation: std. deviation, average, automatical measuring 8 groups and average, accompany waveform, results correctable.
IOL Formula:
SRK-II, SRK-T, BINKHORST,HOLLADAY, HOFFER-Q, HAIGIS
Wooden Box Package
