2.5ton High quality Heli forklift CPD25 environmental forklift electric forklift on sale

2.5ton High quality Heli forklift CPD25 environmental forklift electric forklift on sale

FOB Reference Price: Get Latest Price

≥1 Sets

US $8000

≥5 Sets

US $7200

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Fork Length:: 1070mm

Fork Width:: 125mm, 100mm

Overall Dimensions:: 2070*1070*1995mm

Weight (KG):: 3000 kg

Power type:: Battery/Lithium battery

Quick Details

Min. Lifting Height:: 3000mm

Warranty:: 1 Year

Place of Origin:: Anhui

Fork Length:: 1070mm

Fork Width:: 125mm, 100mm

Overall Dimensions:: 2070*1070*1995mm

Weight (KG):: 3000 kg

Power type:: Battery/Lithium battery

Forklift Video

Product Overview

H4 series

1.5-3.8 ton

battery counterweight forklift

2.5 Ton CPD25

Comfort!!!

Energy Saving!!!

Stable!!!

reliable!!!

Intelligent!!!

secure!!!

Easy to maintain!!!

Wide view frame design, wide front view;

Big handle, large space cockpit design,suitable for people of different heights;
Steering wheel start steering (optional);

P, E, S three-speed adjustment, multi-speed performance free-selected modes;

Instrument table full package design (water cup holder and mobile phone slot);

Intelligent color screen instrument (graphical interface design/Chinese fault display/integrated handheld unit function/optional vehicle networking function); Semi-enclosed cushioned seat, high comfort; LED lighting system, high brightness, long life, more energy saving;

Electric special pattern tire, low damping; Right operation valve stem, good operator comfort;

Standard frame under buffer, optional upper buffer; USB, back lever, warning light, M model standard, S model optional.

CAE analysis and optimization design, component bench test and machine strengthening test; Reliable parts ( 1, casting type steering axle, tapered roller bearing; 2, integral brake drum drive axle, integral cast axle housing, shaft oil seal design, high precision large contact gear; 3, borrow mature internal combustion series door frame main components; 4, sheet metal stamping side cover; 5, all metal punching non-slip pedal);

Good heat dissipation (1, side welded fuel tank; 2, the electric control is placed on the counterweight); Strict test project verification (1, rain test; 2, cold storage test; 3. Vibration test of the whole machine; 4, strengthening test).

Dual core controller;

Driving, hydraulic OPS protection; Hydraulic blast protection, forward tilt self-locking protection;

Electrical multiple protection; Parking safety reminder;

Slope slow slip reminder;

Automatic deceleration when turning.

Flexible (can be carried with the car, can be replaced with the next charge); Pump/pump motor, electric control/main electrical components are located on the counterweight, easy to maintain; Instrument Chinese display, friendly interface.

PRODUCT SPECIFICATIONS

Model	Unit	CPD15	CPD18	CPD20	CPD25	CPD30	CPD35	CPD38
Rated lifting weight	kg	1500	1800	2000	2500	3000	3500	3800
Load center distance	mm	500	500	500	500	500	500	500
Standard door lifting height	mm	3000	3000	3000	3000	3000	3000	3000
Overall length(without fork)	mm	2200	2200	2205/2434	2434	2567	2572	2612
Overall width	mm	1120	1120	1120/1180	1180	1260	1260	1392
Climbing ability when fully loaded	%	17/15	15	15/17	15	17/15	15	15
