Quick Details
-
Place of Origin:
-
Germany
-
Weight:
-
4322 KG
Quick Details
-
Brand Name:
-
tractor
-
Year:
-
2019
-
Make:
-
Tractor
-
Place of Origin:
-
Germany
-
Weight:
-
4322 KG
ELECTRICAL
Alternator: 12 V. 120 A
Battery: 12 V, 96 A
OPERATIONAL
Lift Capacity: 5,500 lbs @2,180 Engine Rpm
Power Take-Off: Independent
Hitch: 3-point category 2 Ball joints with Telescopic
PTO Horsepower: 70 HP (52.2 K W)
PTO Speed: 540 Rpm @ 2,187 Engine Rpm 1,000 Rpm
ENGINE
Engine Type: 4-stroke, Turbocharged
Injection: Direct
Gross Horsepower: 83 Hp (61.9 K W) @ 2,300 Rpm
Cooling: Intercooled
Fuel Type: Diesel
Fuel Tank Capacity: 21.7 Gal
Displacement: 215.4 Ci (3,531.46 Cc)
Cylinders: 4 wet Replaceable Sleeve
| Model | TH1604 | ||||||||||
| Type | 160HP 4WD | ||||||||||
| Size (mm) | Length(to front ballast) | 5050 | |||||||||
| Width | 2230 | ||||||||||
| Height(to top point) | 2900 | ||||||||||
| Wheel Tread | Front Wheel | 1830/1930 Step adjustable | |||||||||
| Rear Wheel | 1630-1830 stepless adjustable | ||||||||||
| Axle Base | 2315 | ||||||||||
| Ground Clearance | 500 | ||||||||||
| Structure weight (kg) | 4400 | ||||||||||
| Engine | Model | Yuchai engine | |||||||||
| Type | 4-Cylinder,Water Cooled | ||||||||||
| Rated Power(kw) | 117.7 | ||||||||||
| Rated speed(r/min) | 2300 | ||||||||||
| Fuel | Diesel | ||||||||||
| Tire | Front Wheel | 13.6-24 | |||||||||
| Rear Wheel | 16.9-38 | ||||||||||
| Clutch | 14'' clutch,Double-stage clutch | ||||||||||
| Steering | Hydraulic steering | ||||||||||
| Transmission Type | 16F+8R | ||||||||||
| Suspension Type | 3-point links | ||||||||||
| PTO | Type and speed | dual speed: 760rpm/850rpm | |||||||||
| Spline Size | I38 Rectangle Spline 00 | ||||||||||
