Quick Details
-
Voltage:
-
according to your design
-
Dimension(L*W*H):
-
6600x2000x2000mm
-
Application:
-
wood working
-
Weight (KG):
-
700 KG
-
Max.Working Width(mm):
-
600mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Low Fuel Consumption Bandsaw Wheels Sawmill Horizontal Bandsaw Sawmill
-
Maximum cutting height:
-
600mm
-
Saw wheel diameter:
-
473mm
-
Max. sawing height:
-
550mm
-
Item:
-
Horizontal Bandsaw Sawmill
-
Bladespeed:
-
900r/min
-
Max. Length of the wood:
-
4000mm
-
The size of saw blade:
-
4005x32x1.05mm
-
External dimension(LxWxH):
-
6500x2000x2200mm
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
NanYang
-
Usage:
-
woodworking
-
Voltage:
-
according to your design
-
Dimension(L*W*H):
-
6600x2000x2000mm
-
Application:
-
wood working
-
Weight (KG):
-
700 KG
-
Max.Working Width(mm):
-
600mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product name:
-
Low Fuel Consumption Bandsaw Wheels Sawmill Horizontal Bandsaw Sawmill
-
Maximum cutting height:
-
600mm
-
Saw wheel diameter:
-
473mm
-
Max. sawing height:
-
550mm
-
Item:
-
Horizontal Bandsaw Sawmill
-
Bladespeed:
-
900r/min
-
Max. Length of the wood:
-
4000mm
-
The size of saw blade:
-
4005x32x1.05mm
-
External dimension(LxWxH):
-
6500x2000x2200mm
MJ375-C Double Cylinder Diesel Horizontal Band saw Machine
——Preferred Machine to Cut Logs and Square Wood
This machine has features like high wood cutting precision, rapid cutting speed, high utilization ratio, good surface smoothness and automatic & simple operation, regarded as the best product to cut softwood and hardwood.
Technical parameters:
|
Specifications and Model |
DIESEL-62 |
Remarks |
|
Maximum Log Diameter |
620mm |
|
|
Saw Wheel Diameter |
473mm |
|
|
Maximum Cutting Height |
620mm |
|
|
Maximum Cutting Width |
620mm |
|
|
Saw wheel Speed: Standard for Common Log |
800-1000 r/min |
|
|
|
||
|
Maximum Cutting Length |
5000mm |
|
|
Diesel Engine Horsepower YM186FA |
16P |
|
|
Blade Dimensions |
4005×34×1.05mm |
|
|
Track Length (Standard) |
6000mm |
|
|
Overall Dimensions |
6000×2000×2000mm |
|
|
Packing Size |
2000×850×2150mm |
|
|
Total Weight (Standard) |
700kg |
|
Advantages:
1.Easy to operate, simple,accurate and safe; easy to maintenance and move.
2.Big power, low fuel consumption;
3.High cutting efficiency, small kerf and smooth; high flatness of the cutting plate;
4.Long service life of saw blade, grinding blade automatic and simple.
5.Apply to sawing process for the forest and without electricity area.
6.There’s no need the professional sawyers, the ordinary workers can operate the machine expertly.
1. All the prices are FOB Shanghai. Include packing charge;
2. Payment Terms: T/T 30% as deposit after signing contract, and 70% before shipment;
3. Delivery Time: Within 30 days after receiving the deposit.
