Quick Details
-
Name:
-
Automatic Parcel Delivery Locker
-
Material:
-
Cold Rolled Steel
-
Color:
-
Customized
-
Lock:
-
Electronic Lock
-
Certification:
-
ISO900/CE/ETL/RoHS
-
Description:
-
Logistics Distribution System Parcel Lockers
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZHILAI
-
Model Number:
-
PL-34
-
Name:
-
Automatic Parcel Delivery Locker
-
Material:
-
Cold Rolled Steel
-
Color:
-
Customized
-
Lock:
-
Electronic Lock
-
Certification:
-
ISO900/CE/ETL/RoHS
-
Description:
-
Logistics Distribution System Parcel Lockers
Product Application Delivery Last Mile Solution
Smart parcel locker is the effective solution of the last 100 meters delivery. Zhilai Smart Parcel Locker takes the form of storage lockers to place them in the community to build a safe parcel delivery and pick-up bridge for the property companies, courier corporate and the recipients.
"Quick, Convenient, and Secure Pick-up Anytime"
Product configuration
Notice:
34
doors Parcel Lockers can increase the times of 20 doors additional to combine into
54
door lockers,
74
door lockers, and
94
door lockers, etc. .
Optional colors:
Customized, any Pantone color is available
Main Features:
• Place a parcel (using pin code, barcode or qr-code)
• Receive a parcel using barcode (using pin code, barcode or qr-code)
• User interface
• Courier interface
• Server interface
3. Within server software includes following user roles :
• Supervisor
• Logistics manager
• Courier
• Logistics company
4. Server software allows to monitor lockers remotely, controlling their performance and functionality.
• Return of parcels by the customer
• "Pay as receive" option via built-in bill acceptor or card-reader
• C2C service
• Last mile service
• Reverse logistics
• Flash sale (vending machine functionality)
• Exchange services
Usage method:
Main component:
The main control system, door open system, LCD display, touch screen, scan module, reader module, metal keyboard, infrared detection module, network module, expandable monitoring system, POS machine, and identity verification system etc..
Function:
Smart Parcel Locker takes the technology of metal structure, embedded computing, machine scanning module, wireless network module, metal keyboard,
LCD display, industrial touch screen, patented electric control lock and management software to smoothly ensure the safety of the parcel delivery and receipt.
Material:
①. The cabinet takes the1.0mm thickness of cold steel plate with surface spraying.
②. The door takes 2.0mm thickness of cold electrolysis steel sheet surface with electrophoresis processing and then spray.
With CE and ETL certificates, our smart parcel locker has been exported to many countries and regions in the world. We have successfully cooperated with Amazon, Smart Carte Inc.
In US and Europe since 2010 ZHILAI has cooperated with the commercial giant Amazon in US. Amazon lockers, designed and manufactured by ZHILAI, are all over states of USA, the whole UK and some Europe and countries now.
Characteristics
1. Efficient
With long-range control and real-time monitor,the system can efficiently and promptly deal with the locker malfunctions, which sharply decreases the amount of spot working.
2. Stable & Reliable
Zhilai Smart Parcel Lockers are with high stability
and reliability which has been proven by Amazon Locker over six years practice in the overseas locations. Also in China, Zhilai Smart Parcel Lockers system is running properly over 3,000 lockers located in different estates at present.
3. Various sizes
Modular construction of the body of terminal enables configuration of machines in various sizes and with different numbers of lockers suitable for both indoor and outdoor locations.
Hardware advantages:
• Flexibility. Adjustable cell size for different type of packages, screen size.
• Scalability. Connect up to 64 add-on units.
• Reliability. Built-in self-control media, power drops protection.
• Customize your system with custom paint, wraps, or branding.
• Heavy-duty corrosion-resistant steel with long-lasting powder coat paint.
• Simplicity. Easy to install and operate.
• Machine construction does not contain complex circuit
modules.
• Easy moving due to dimensions fitting to standard doorways and cargo lift cabins.
• Complete installation may be implemented by 1-2 persons.
• Reliable brand-name hardware and electronic components
.
Software advantages:
• Open source. We provide our customers initial code together with shipment.
• Affordable. No royalty or rental fee or any other hidden payments.
• Flexible system architecture. Our software may be adjusted to any customers' needs.
• Easy software installation with automatic set-up using pin code, barcode or QR-codes.
• Multilingual interface.
• Graphics and interface adjustable to your branding.
• Compatible with all types of internet connection (Wi-Fi, Ethernet, 3G/4G).
• Web security due to OpenVPN usage.
• Fault tolerance. Server part may work in cluster.
• May use iPX. media for simultaneous set-up of almost infinite number of workstations via Internet
.
