Quick Details
-
Model Number:
-
hdpe double wall corrugate pipes
-
Specification:
-
DN20mm-DN1600mm
-
Length:
-
6m or As required
-
Thickness:
-
sd9-sd41 or As required
-
Standard:
-
ISO4427/ IPS/DIPS
-
Product name:
-
hdpe double wall corrugate pipes
-
Color:
-
Blue and black or As required
-
Application:
-
Conveying Water
-
Feature:
-
Durable
-
MOQ:
-
1000 Meters
-
OEM:
-
Accpet
-
Size:
-
DN110-DN1600mm or As required
-
Type:
-
Round Pipe
-
Certification:
-
ISO 9001:2000/ISO 14001:2004
-
operating temperature range:
-
-60℃~60℃
Quick Details
-
Processing Service:
-
Moulding, Cutting
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
exlon
-
Model Number:
-
hdpe double wall corrugate pipes
-
Specification:
-
DN20mm-DN1600mm
-
Length:
-
6m or As required
-
Thickness:
-
sd9-sd41 or As required
-
Standard:
-
ISO4427/ IPS/DIPS
-
Product name:
-
hdpe double wall corrugate pipes
-
Color:
-
Blue and black or As required
-
Application:
-
Conveying Water
-
Feature:
-
Durable
-
MOQ:
-
1000 Meters
-
OEM:
-
Accpet
-
Size:
-
DN110-DN1600mm or As required
-
Type:
-
Round Pipe
-
Certification:
-
ISO 9001:2000/ISO 14001:2004
-
operating temperature range:
-
-60℃~60℃
high quality 10 inch 300mm 500mm 600mm 8 inch smooth interior polyethylene hdpe double wall corugate culvert drainage pipe
|
Supply
|
HDPE Corrugated Pipes and Fittings
|
|
Standard
|
ISO4427/ IPS/DIPS
|
|
Sizes
|
DN225-DN800 or Custom
|
Products Description
|
Name
|
HDPE Double Wall Corrugated Pipe
|
|
Size:
|
DN225-DN800mm or custom
|
|
Application
|
Hdpe Water Drain Pipe
|
|
Type
|
Round Pipe
|
|
Color
|
Blue and black or custom
|
|
Standard
|
ISO4427/ IPS/DIPS
|
|
Certification
|
ISO 9001:2000/ISO 14001:2004
|
Product Paramenters
Specification parameters of double-wall Bellows
|
The Specification of HDPE Double-Wall Corrugated Pipe
|
|
|
|
|
|
|
||||||
|
DN/ID
|
Min ID
|
OD
|
O.D.tolerance
|
Min Thinkness
|
Bellmouth ID
|
Min Bellmouth ID
|
||||||
|
225
|
220
|
255
|
±3
|
≥1.7
|
264-269
|
≥55
|
||||||
|
300
|
294
|
330
|
±3
|
≥2.0
|
348-351
|
≥64
|
||||||
|
400
|
392
|
456
|
±3
|
≥2.5
|
465-469
|
≥74
|
||||||
|
500
|
490
|
572
|
±3
|
≥3.0
|
549-553
|
≥85
|
||||||
|
600
|
588
|
690
|
±3
|
≥3.5
|
668-672
|
≥96
|
||||||
|
800
|
785
|
925
|
±3
|
≥4.5
|
888-895
|
≥118
|
||||||
Details Images
HANDLING
Do ✔
Store pipe on firm and flat surfaces.
Keep pipe and fttings away from sharp objects, heat,and toxic and aggressive materials.
Take carenot tocut,kink,abrade,or otherwise damage the pipe during handling.
Keep protective packaging intact until pipes and fittings are required for use.
Release coils carefully,keeping in mind they may be coiled under tension.
Take care when handling pipe under wet or frosty conditions,as the pipe may become slippery.
Temporarily cap cut pipe ends to prevent dirt or other material from entering the pipe.
Uncoil pipe and allow it to warm in the sun before burial for ease of installation.
DON"T ❌
Throw pipe from delivery vehicles.· Drag pipe or roll pipe coils.
Place pipeand fittings incontact withlubricating oil,gasoline,solvents,or other aggressive materials.Heat pipe with an open flame.
Customer Photos
Applications
HDPE Pipe Applications
HDPE pipes are used in varied industries like Agriculture, Chemical, Industrial, Sewage and Drainage, Sprinkler Irrigation, Industrial Effluents and House services connection works as well.
Product packaging
