0.7-10KW 1-3 MPPTs
Single Phase 220-240V 50/60Hz
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Solis
-
Model Number:
-
Solis 3-6Kw-HY
-
Input Voltage:
-
90-520 V
-
Output Voltage:
-
1/N/PE, 220 V / 230 V
-
Output Current:
-
13A
-
Output Frequency:
-
50/60Hz
-
Size:
-
333*505*249mm
-
Certificate:
-
CE/IEC
-
Warranty:
-
10 Years
-
Weight:
-
18.3 kg
-
Product name:
-
Solis Hybrid Inverter
-
PV Input Power:
-
7-8KW
-
MPPT Voltage Range:
-
90-520V
-
Battery Voltage Range:
-
42-58V
-
Output AC (Back-up):
-
3-5KW
-
Output AC (Grid side):
-
3-6KW
-
Topology:
-
High frequency isolation (for battery)
-
Protection Degree:
-
Ip65
-
Cooling concept:
-
Natural convection
-
Communication:
-
RS485, Optional: Wi-Fi, GPRS
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/DC Converters, DC/AC Inverters, AC to AC
-
Inverter Efficiency:
-
99.9%
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Solis
-
Model Number:
-
Solis 3-6Kw-HY
-
Input Voltage:
-
90-520 V
-
Output Voltage:
-
1/N/PE, 220 V / 230 V
-
Output Current:
-
13A
-
Output Frequency:
-
50/60Hz
-
Size:
-
333*505*249mm
-
Certificate:
-
CE/IEC
-
Warranty:
-
10 Years
-
Weight:
-
18.3 kg
-
Product name:
-
Solis Hybrid Inverter
-
PV Input Power:
-
7-8KW
-
MPPT Voltage Range:
-
90-520V
-
Battery Voltage Range:
-
42-58V
-
Output AC (Back-up):
-
3-5KW
-
Output AC (Grid side):
-
3-6KW
-
Topology:
-
High frequency isolation (for battery)
-
Protection Degree:
-
Ip65
-
Cooling concept:
-
Natural convection
-
Communication:
-
RS485, Optional: Wi-Fi, GPRS
Products Description
Technical specifications
|
Model Name
|
|
RHI-3K-48ES-5G
|
|
RHI-3.6K-48ES-5G
|
RHI-4.6K-48ES-5G
|
RHI-5K-48ES-5G
|
RHI-6K-48ES-5G
|
|||||||
|
Input DC (PV side)
|
|
|
|
|
|
|
|
|||||||
|
Recommended max. PV power
|
|
7 kW
|
|
7 kW
|
8 kW
|
8 kW
|
8 kW
|
|||||||
|
Max. input voltage
|
|
600 V
|
|
|
|
|
|
|||||||
|
Rated voltage
|
|
330 V
|
|
|
|
|
|
|||||||
|
Start-up voltage
|
|
120 V
|
|
|
|
|
|
|||||||
|
MPPT voltage range
|
|
90-520 V
|
|
|
|
|
|
|||||||
|
Max. input current
|
|
11 A / 11 A
|
|
|
|
|
|
|||||||
|
Max. short circuit current
|
|
17.2 A / 17.2 A
|
|
|
|
|
|
|||||||
|
MPPT number/Max. input strings number
|
|
2/2
|
|
|
|
|
|
|||||||
|
Battery
|
|
|
|
|
|
|
|
|||||||
|
Battery type
|
|
Li-ion / Lead-acid
|
|
|
|
|
|
|||||||
|
Battery voltage range
|
|
42 - 58 V
|
|
|
|
|
|
|||||||
|
Battery capacity
|
|
50 - 2000 Ah
|
|
|
|
|
|
|||||||
|
Max. charge / discharge power
|
|
3 kW
|
|
|
5 kW
|
|
|
|||||||
|
Max. charge / discharge current
|
|
62.5 A
|
|
|
100 A
|
|
|
|||||||
|
Communication
|
|
CAN
|
|
|
|
|
|
|||||||
|
Output AC (Back-up)
|
|
|
|
|
|
|
|
|||||||
|
Rated output power
|
|
3 kW
|
|
|
5 kW
|
|
|
|||||||
|
Max. apparent output power
|
|
4 kVA
|
|
|
6 kVA
|
|
|
|||||||
|
Back-up switch time
|
|
<20 ms
|
|
|
|
|
|
|||||||
|
Rated output voltage
|
|
1/N/PE, 220 V / 230 V
|
|
|
|
|
|
|||||||
|
Rated frequency
|
|
50 Hz / 60 Hz
|
|
|
|
|
|
|||||||
|
Rated output current
|
|
13.6 A / 13 A
|
|
|
22.7 A / 22 A
|
|
|
|||||||
|
THDv (@linear load)
|
|
<2%
|
|
|
|
|
|
|||||||
|
Input AC (Grid side)
|
|
|
|
|
|
|
|
|||||||
|
Input voltage range
|
|
184-264 V
|
|
|
|
|
|
|||||||
|
Max. input current
|
|
26.1 A
|
|
|
|
|
|
|||||||
|
Frequency range
|
|
45-55 Hz / 55-65 Hz
|
|
|
|
|
|
|||||||
|
Output AC (Grid side)
|
|
|
|
|
|
|
|
|||||||
|
Rated output power
|
|
3 kW
|
|
3.6 kW
|
4.6 kW
|
5 kW
|
6 kW
|
|||||||
|
Max. apparent output power
|
|
3.3 kVA
|
|
4 kVA
|
4.6 kVA
|
5.5 kVA
|
6 kVA
|
|||||||
|
Operation phase
|
|
1/N/PE
|
|
|
|
|
|
|||||||
|
Rated grid voltage
|
|
220 V / 230 V
|
|
|
|
|
|
|||||||
|
Rated grid frequency
|
|
50 Hz / 60 Hz
|
|
|
|
|
|
|||||||
|
Rated grid output current
|
|
13.6 A / 13 A
|
|
16.3 A / 15.7 A
|
20.9 A / 20 A
|
22.7 A / 21.7 A
|
27.2 A / 26.1 A
|
|||||||
|
Max. output current
|
|
15.7 A
|
|
17.3 A
|
23 A
|
23.9 A
|
26.1 A
|
|||||||
|
Power Factor
|
|
>0.99 (0.8 leading - 0.8 lagging)
|
|
|
|
|
|
|||||||
|
THDi
|
|
<2%
|
|
|
|
|
|
|||||||
|
Efficiency
|
|
|
|
|
|
|
|
|||||||
|
Max. efficiency
|
|
>97.5%
|
|
|
|
|
|
|||||||
|
EU efficiency
|
|
>96.8%
|
|
|
|
|
|
|||||||
|
Protection
|
|
|
|
|
|
|
|
|||||||
|
DC reverse-polarity protection
|
|
Yes
|
|
|
|
|
|
|||||||
|
Short circuit protection
|
|
Yes
|
|
|
|
|
|
|||||||
|
Output over current protection
|
|
Yes
|
|
|
|
|
|
|||||||
|
Surge protection
|
|
DC Type II / AC Type II
|
|
|
|
|
|
|||||||
|
Ground fault monitoring
|
|
Yes
|
|
|
|
|
|
|||||||
|
Integrated AFCI (DC arc-fault circuit protection)
|
|
Yes (1)
|
|
|
|
|
|
|||||||
|
Protection class/Over voltage category
|
|
I/II
|
|
|
|
|
|
|||||||
|
General Data
|
|
|
|
|
|
|
|
|||||||
|
Dimensions (W*H*D)
|
|
333*505*249 mm
|
|
|
|
|
|
|||||||
|
Weight
|
|
18.3 kg
|
|
|
|
|
|
|||||||
|
Topology
|
|
High frequency isolation (for battery)
|
|
|
|
|
|
|||||||
|
Operating ambient temperature range
|
|
-25 ~ +60°C
|
|
|
|
|
|
|||||||
|
Ingress protection
|
|
IP65
|
|
|
|
|
|
|||||||
|
Cooling concept
|
|
Natural convection
|
|
|
|
|
|
|||||||
|
Max. operation altitude
|
|
2000 m
|
|
|
|
|
|
|||||||
|
Grid connection standard
|
|
G98 or G99, VDE-AR-N 4105 / VDE V 0124, EN 50549-1, VDE 0126 / UTE C 15 / VFR:2019, RD 1699 / RD 244 / UNE 206006 / UNE 206007-1,
CEI 0-21, C10/11, NRS 097-2-1, TOR, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA
|
|
|
|
|
|
|||||||
|
Safety/EMC standard
|
|
IEC/EN 62109-1/-2, EN 61000-6-2/-3
|
|
|
|
|
|
|||||||
|
Features
|
|
|
|
|
|
|
|
|||||||
|
DC connection
|
|
MC4 connector
|
|
|
|
|
|
|||||||
|
AC connection
|
|
Quick connection plug
|
|
|
|
|
|
|||||||
|
Display
|
|
7.0"LCD color screen display
|
|
|
|
|
|
|||||||
|
Communication
|
|
RS485, Optional: Wi-Fi, GPRS
|
|
|
|
|
|
|||||||
