Quick Details
-
Brand Name:
-
SANPU
-
Model Number:
-
PS35-W1V
-
Output Frequency:
-
47~63Hz
-
Output Current:
-
0~5A
-
Input Voltage:
-
220V
-
Output:
-
Constant voltage
-
Size:
-
85*58*35mm
-
weight:
-
0.16kg
-
packing:
-
100pcs/16Kg
-
certificates:
-
CE ROHS
-
material:
-
metal
-
warranty:
-
2 years
-
life span:
-
50000h
-
MOQ:
-
negotiable
Quick Details
-
Output Power:
-
1 - 50W
-
Output Voltage:
-
5V,12V, 15V, 24V,
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SANPU
-
Model Number:
-
PS35-W1V
-
Output Frequency:
-
47~63Hz
-
Output Current:
-
0~5A
-
Input Voltage:
-
220V
-
Output:
-
Constant voltage
-
Size:
-
85*58*35mm
-
weight:
-
0.16kg
-
packing:
-
100pcs/16Kg
-
certificates:
-
CE ROHS
-
material:
-
metal
-
warranty:
-
2 years
-
life span:
-
50000h
-
MOQ:
-
negotiable
Features
1. ac dc automatic transfer switch 5v 12v
2.Protections: short circuit/ over load/ over voltage/ over temp
3. Conform to EN60950 GB4943 UL60950 Safety standards
4. Conform to CB9254 EN55022 EMC Standards
5. High quality with competitive price
6. Suitable for any where in the world
7. Built-in EMI filter with tiny ripple
8. Two years warranty
|
AC input voltage range |
85~132VAC 47~63Hz |
||||
|
Input current |
0.9A/110V 0.45A/230V |
||||
|
AC inrush current |
Cold-start current 36A/230V |
||||
|
Leakage current |
<2MA/240VAC |
||||
|
DC adjustable range |
±10% rated output voltage |
||||
|
Over load protection |
105~135% hiccup mode, auto-recovery |
||||
|
Over-temp protection |
Rectifier≥90°C cut off the output, auto-recovery |
||||
|
Setup, rise, hold up time |
200ms, 100ms, 30ms |
||||
|
Withstand voltage |
I/P- O/P: 1.5KVAC 1 minute I/P- FG: 1.5KVAC 1 minute O/P- FG: 0.5KVAC 1minute |
||||
|
Working temperature |
-20 °C ~+60°C, 20%~90%RH |
||||
|
Weight/ packing/ size |
0.16Kg, 100pcs/16.Kg, 85*58*35(mm) |
||||
|
Model |
Output |
Error |
Range |
Efficiency |
|
|
PS 35- W1V5 |
5V |
0~5A |
± 2% |
80mv |
76% |
|
PS 35- W1V12 |
12V |
0~3A |
± 1% |
100mv |
78% |
|
PS 35- W1V15 |
15V |
0~2.4A |
± 1% |
100mv |
80% |
|
PS 35- W1V24 |
24V |
0~1.5A |
± 1% |
150mv |
80% |
