- Product Details
- {{item.text}}
Quick Details
-
Panel Dimensions:
-
2176mm x 1098mm x 35mm
-
Panel Efficiency:
-
21.3%
-
Application:
-
Solar Power System
-
Cell Type:
-
182*182mm
-
Weight:
-
25.1kg
-
Junction Box:
-
IP68, 3 diodes
-
Connector:
-
PV Compatible Connector
-
Packing:
-
31pcs per pallet
-
40HQ':
-
682pcs
-
Frame:
-
Customizable black frame
-
OEM Order:
-
Acceptable
-
Frame Color:
-
White / Black
Quick Details
-
Brand Name:
-
Moregosolar
-
Model Number:
-
MG03-M66S-495W~505W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2176mm x 1098mm x 35mm
-
Panel Efficiency:
-
21.3%
-
Application:
-
Solar Power System
-
Cell Type:
-
182*182mm
-
Weight:
-
25.1kg
-
Junction Box:
-
IP68, 3 diodes
-
Connector:
-
PV Compatible Connector
-
Packing:
-
31pcs per pallet
-
40HQ':
-
682pcs
-
Frame:
-
Customizable black frame
-
OEM Order:
-
Acceptable
-
Frame Color:
-
White / Black
|
MECHANICAL SPECIFICATION
|
|
|
|
Module Dimensions
|
2176mm x 1098mm x 35mm
|
|
|
Weight
|
26.3kg±3%
|
|
|
Cell
|
150 monocrystalline cells
|
|
|
Junction Box
|
IP68, 3 diodes
|
|
|
Cable
|
4mm2, 1200mm in length, length can be customized
|
|
|
Nominal Max. Power (Pmax)
|
495W
|
500W
|
505W
|
|
Open Circuit Voltage (Voc)
|
42.6V
|
42.8V
|
43.0V
|
|
Short Circuit Current (Isc)
|
11.63A
|
11.69A
|
11.75A
|
|
Opt. Operating Voltage (Vmp)
|
51.5V
|
51.7V
|
51.9V
|
|
Opt. Operating Current (Imp)
|
12.21A
|
12.28A
|
12.35
|
|
Module Efficiency
|
20.7%
|
20.9%
|
21.1%
|
|
PACKAGING
|
|
|
|
Model
|
MG03-M66S 490-505W
|
|
|
Model per Pallet
|
31 pieces
|
|
|
Model per 40' Container
|
682 pieces
|
|
|
Note: The above packing information contained in this web is subject to change without notice. We will offer wooden box packing
with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests. |
|
|
