- Product Details
- {{item.text}}
Quick Details
-
Weight (KG):
-
2 KG
-
Material:
-
Aluminum alloy
-
Size:
-
90*100*35
-
Application:
-
Wood Planing
-
usage:
-
planing wood straight
-
Type:
-
Plan machine Parts
-
Item:
-
Spindle Moulder Cutter Head
Quick Details
-
Place of Origin:
-
Fujian, China
-
Marketing Type:
-
New Product 2024
-
Brand Name:
-
LIVTER
-
Weight (KG):
-
2 KG
-
Material:
-
Aluminum alloy
-
Size:
-
90*100*35
-
Application:
-
Wood Planing
-
usage:
-
planing wood straight
-
Type:
-
Plan machine Parts
-
Item:
-
Spindle Moulder Cutter Head
pay attention
ATTENTION PLEASE
Technical Imformation:
a.
Superrior blade edge angle design provides smoothness of cutting,low noise cutting and low cutting resistance.
b. Blades and cutterhead feature long service life.
c. Easy setups for blade position and cutterhead.
d. Reduced setup time and machine downtime provides improved efficiency.
e. The cutterhead is dynamically balanced fou smooth running.
f. Fitted with 4-edge T.C.T.knife inserts.
b. Blades and cutterhead feature long service life.
c. Easy setups for blade position and cutterhead.
d. Reduced setup time and machine downtime provides improved efficiency.
e. The cutterhead is dynamically balanced fou smooth running.
f. Fitted with 4-edge T.C.T.knife inserts.
Advantage:
- Provide rtificial alloy blade edge cutting time for twenty or thirty days ,effctive and dispense everyday knife blade on the knife of trouble,really"making a fool of life " .Efficiency of high speed,more edge,but cutting depth,feed speed,360 degrees ofdot cutting,cutting force,save electricity by 50%.
- Laceration resistant the blade spiral arrangement design.High hardness,dealing with distorted lines,reverse grain,wood knot,hardwood softwood cutting.
- Modular design,uses the modular desigh,blade length can be infinite length and uses the edge structure,is the ultimate choice of big flat planing.
Product Details:
Product Specifications:
| ITEM NO | ΦD(mm) | W(mm) | Φd(mm) | Z | Knives(pcs) |
| ST615 100060 | 100 | 60 | 30/35/40 | 6 | 15 |
| ST615 100080 | 100 | 80 | 30/35/40 | 6 | 18 |
| ST615 100100 | 100 | 100 | 30/35/40 | 6 | 24 |
| ST615 100130 | 100 | 130 | 30/35/40 | 6 | 30 |
| ST615 100140 | 100 | 140 | 30/35/40 | 6 | 33 |
| ST615 100150 | 100 | 150 | 30/35/40 | 6 | 36 |
| ST615 100180 | 100 | 180 | 30/35/40 | 6 | 42 |
| ST615 125060 | 125 | 60 | 40/50 | 6 | 15 |
| ST615 125080 | 125 | 80 | 40/50 | 6 | 18 |
| ST615 125100 | 125 | 100 | 40/50 | 6 | 24 |
| ST615 125130 | 125 | 130 | 40/50 | 6 | 30 |
| ST615 125150 | 125 | 150 | 40/50 | 6 | 36 |
| ST615 125180 | 125 | 180 | 40/50 | 6 | 42 |
| ST615 125200 | 125 | 200 | 40/50 | 6 | 48 |
| ST615 125230 | 125 | 230 | 40/50 | 6 | 54 |
