Quick Details
-
Brand Name:
-
no
-
Place of Origin:
-
China
-
Model Number:
-
Super CUB
-
Color:
-
Red/Blue/Green/Black/Camouflage etc
-
Max torque:
-
7.2N.m/5500rpm
-
Clutch:
-
Manual Clutch
-
Engine:
-
4 Stroke Air-cooled
-
Fuel:
-
Gas
Quick Details
-
Displacement:
-
100-200CC
-
Max. Speed:
-
> 80km/h
-
Motor:
-
Other
-
Brand Name:
-
no
-
Place of Origin:
-
China
-
Model Number:
-
Super CUB
-
Color:
-
Red/Blue/Green/Black/Camouflage etc
-
Max torque:
-
7.2N.m/5500rpm
-
Clutch:
-
Manual Clutch
-
Engine:
-
4 Stroke Air-cooled
-
Fuel:
-
Gas
Product Introduction
Specification
|
MAIN FUNCTIONS
|
|
|
|
Size (LXWXH) :1900×680×1100mm
|
Displacement:106.7
|
|
|
Wheelbase 1190mm
|
Compression Ratio:9:1
|
|
|
Engine model: YX110/C110/Z110/YB110
|
Carburetor: Equal vacuum type
|
|
|
Ground Clearance: 130mm
|
Max power:5.1kw/8000r/min
|
|
|
Engine type: Single-cylinder Air-cooled, 4-stroke
|
Max. torque:7.2N•m(5000 r/min)
|
|
|
Fuel Capacity (l): 4.3L
|
Ignition: CDI
|
|
|
Wheels Front/rear: Spoke/Aluminum rim
|
Starter: Electric/kick
|
|
|
Types Front: 2.50-17L/175Kpa
|
Shift type: 1-N-2-3-4
|
|
|
Types Rear: 2.75-17P/225Kpa
|
Drive Train: Chain
|
|
|
Suspensions Front/Rear:Telescopic, coil spring, oil damped / Swing arm type, coil spring, oil damped
|
Spark plug:A6RTC/CR6HSA
|
|
|
Brakes Front:Drum/Disk
|
Bore×Stroke: 52.4×49.5mm
|
|
|
Brakes Rear: Drum Brake
|
Max. loading: 150kg
|
|
|
Dry Weight: 95kg
|
Climbing ability: ≥16°
|
|
|
Min fuel: 1.4L/100km
|
|
|
