- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Lite
-
Model Number:
-
Ceramic Fiber Bulk
-
Application:
-
lining of furnace
-
Dimensions:
-
High Alumina cotton
-
Working Temperature:
-
1000-1400C
-
Fiber Diameter:
-
2-3um
-
Thermal Conductivity:
-
0.6w/m.k
-
Shrinkage (1800℉, 3h):
-
-3%
-
Product name:
-
insulation ceramic fiber products
-
Material:
-
High Alumina Wool
-
Color:
-
White
-
Certificate:
-
ISO9001:2000
-
Feature 1:
-
Excellent Thermal Shock Resistance
-
Feature 2:
-
Low Thermal Conductivity
-
Type:
-
Insulation Heat
-
Package:
-
Carton
-
Size:
-
Customer's Demand
-
Shape:
-
Cotton Fiber Bulk
Quick Details
-
Ultimate Strength (≥ MPa):
-
0.04Mpa
-
Density (kg/m³ ):
-
128
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Lite
-
Model Number:
-
Ceramic Fiber Bulk
-
Application:
-
lining of furnace
-
Dimensions:
-
High Alumina cotton
-
Working Temperature:
-
1000-1400C
-
Fiber Diameter:
-
2-3um
-
Thermal Conductivity:
-
0.6w/m.k
-
Shrinkage (1800℉, 3h):
-
-3%
-
Product name:
-
insulation ceramic fiber products
-
Material:
-
High Alumina Wool
-
Color:
-
White
-
Certificate:
-
ISO9001:2000
-
Feature 1:
-
Excellent Thermal Shock Resistance
-
Feature 2:
-
Low Thermal Conductivity
-
Type:
-
Insulation Heat
-
Package:
-
Carton
-
Size:
-
Customer's Demand
-
Shape:
-
Cotton Fiber Bulk
Product Description
Specification
|
Grade
|
|
Common
|
Standard
|
High Pure
|
High Alumina
|
Zirconium
|
|
|
Max.Temperature (℃)
|
|
1100
|
1260
|
1260
|
1300
|
1430
|
|
|
Working Temperature (℃)
|
|
<1000
|
1150
|
1200
|
1260
|
1400
|
|
|
Fiber diameter(um)
|
Blown
|
2-3
|
2-3
|
2-3
|
2-3
|
2-3
|
|
|
|
Needled
|
3-4.5
|
3-4.5
|
3-4.5
|
3-4.0
|
3-4.0
|
|
|
Chemical composition
(%) |
AL2O3
|
44
|
46
|
47-49
|
52-55
|
39-40
|
|
|
|
Al2O3+SiO2
|
96
|
96
|
99
|
99
|
-
|
|
|
|
Al2O3+SiO2+ZrO2
|
-
|
-
|
-
|
-
|
99
|
|
|
|
ZrO2
|
-
|
-
|
-
|
-
|
15-17
|
|
|
|
Fe2O3
|
<1.2
|
<1.0
|
0.2
|
0.2
|
0.2
|
|
|
|
Na2O+K2O
|
≤0.5
|
≤0.5
|
0.2
|
0.2
|
0.2
|
|
Packing & Delivery
Standard Dimension.
Density: 96,128,160kg/m3
Dimension: 15240/14640/14400×610×13 mm
7620/7320/7200×610×25mm
3810/3660/3600×610×50 mm
Packing: woven bag/carton
Loading: 220 cartons/20 GP, 525 cartons/40 HQ
Density: 96,128,160kg/m3
Dimension: 15240/14640/14400×610×13 mm
7620/7320/7200×610×25mm
3810/3660/3600×610×50 mm
Packing: woven bag/carton
Loading: 220 cartons/20 GP, 525 cartons/40 HQ
