Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
yinhe
-
color:
-
any
-
Surface treatment:
-
HDG and power coating ,painting
-
Torlance:
-
+- 2%
-
Standard:
-
ISO
-
Welding standard:
-
AWS D 1.1
-
Gavanization standard:
-
ASTM A 123
-
Warranty:
-
15 years
-
Manufactury capacity:
-
300 pieces per day
Quick Details
-
Material:
-
Steel
-
Type:
-
any
-
Application:
-
any
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
yinhe
-
color:
-
any
-
Surface treatment:
-
HDG and power coating ,painting
-
Torlance:
-
+- 2%
-
Standard:
-
ISO
-
Welding standard:
-
AWS D 1.1
-
Gavanization standard:
-
ASTM A 123
-
Warranty:
-
15 years
-
Manufactury capacity:
-
300 pieces per day
11kv electric concrete pole making machine 500Dan Multisided:
|
Height |
From 6 m to 15 m |
|
Suit for |
Airport ,seaport,plaza,stadium ,square,highway,street way etc |
|
Shape |
Conoid ,Multi-pyramidal,Columniform , polygonal or conical
|
|
Material |
Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52- |
|
Lamp power |
20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz |
|
Torlance of the dimenstion |
+- 2% |
|
Optical assembly of lighting fixture |
IP 65 |
|
Electroshock resistant protective grade |
Grade Ⅰ |
|
The casing anti-corrosion performance |
Class Ⅱ |
|
Working atmosphere of lighting fixture |
-35 °C ~+45 °C |
|
Surface treatment |
Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
|
|
Joint of Poles |
Insert mode,innerflange mode,face to face joint mode .
|
|
Design of pole |
Against earthquake of 8 grade |
|
Wind Speed |
160 Km/Hour |
|
Minimum yield strength |
355 mpa |
|
Minimum ultimate tensile strength |
490 mpa |
|
Max ultimate tensile strength |
620 mpa |
|
Standard |
ISO 9001 |
|
Length of per section |
Within 14m once forming without slip joint |
|
Welding |
We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
|
|
Thickness |
1 mm to 30 mm |
|
Production Process |
Rew material test → Cuttingj → Molding or bending → Welidng (longitudinal ) → Dimension verify → Flange welding → Hole drilling → Calibration → Deburr → Galvanization or powder coating ,painting → Recalibration → Thread → Packages |
|
Packages |
Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.
|
|
Style |
Size and styles are veriable as per customer request |
Our product:
Specification:
Our design:
Material introduction:
Production process:
Trade Terms: 1. Payment:(1)Telegraphic Transfer(30% advance payment, balance before shipment)
(2)Telegraphic Transfer(30% advance payment, balance against copy of documents)
(3)Letter of Credit: at sight
2. Lead Time: 2 weeks after confirmed order
3. Delivery way: by sea
Application: Street Lighting
Our Service: 1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more than 20 years, competitive with good quantity.
7 Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.
8. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.
Our steel pole, steel poles , steel power poles ,power steel poles, electrical poles, electrical power poles, power poles, power distribution equipment poles , electric power transimission &distribution steel poles ,hot-dip-galvanized steel poles ,lamp poles ,road poles, streeting lighting poles, street lamp poles ,solar street lamps steel poles ,high mast lamp poles,road lamp poles, the steel street lamp poles, hot-dip-galvanized steel lighting ,outdoor lighting ,outdoor lamps ,street lighting poles ,steel post ,street poles, lamp parts ,lighting fixture ,lighting poles ,lighting equipment ,lighting decoration ,lighting product , street lighting body, high mast lighting steel poles &tower,electric poles, round&square street lighting steel poles with double arm or single arm . Stainless steel poles, Flag mast stainless steel pole, aluminum street light poles, traffic lighting steel poles, telecom tower poles , baseplate , bearing plate, base flanges , are made by hot-roll steel coil ,the process as cut plate, bending ,forming,automatic welding,drill holes ,quality check before galvanized, hot dip galvanized or powder coating , final quality check according by client required.
