- Product Details
- {{item.text}}
Quick Details
-
Dimension (L*W*H):
-
482*390*133mm
-
Weight:
-
30kg
-
Model No.:
-
25.6V 100AH
-
Products name:
-
24V Battery
-
Capacity:
-
100Ah
-
OEM/ODM:
-
Accepatable
-
Voltage:
-
25.6V
-
Application:
-
solar Power Systems
-
Usage:
-
Energy Storage system
-
Warranty:
-
5years
-
Product Life:
-
Over 10 years
-
Customized Solar Systems:
-
Available
Quick Details
-
Model Number:
-
25.6V 100AH
-
Brand Name:
-
Basen Green
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
482*390*133mm
-
Weight:
-
30kg
-
Model No.:
-
25.6V 100AH
-
Products name:
-
24V Battery
-
Capacity:
-
100Ah
-
OEM/ODM:
-
Accepatable
-
Voltage:
-
25.6V
-
Application:
-
solar Power Systems
-
Usage:
-
Energy Storage system
-
Warranty:
-
5years
-
Product Life:
-
Over 10 years
-
Customized Solar Systems:
-
Available
Products Description
Applications:
1.Energy Storage
--Solar-Wind Power System / City Grid (On/Off) / Community and Family
2.Back-up System and UPS
--Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / power Equipment
3.Other Applications
--Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
--RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard / Electric bike / Electric Scooter / Electric
bicycle
--LED Backup / Engine Starting Battery,etc
|
Model
|
24V100Ah
|
|
Nominal Voltage
|
25.6V
|
|
Nominal Capacity
|
100Ah
|
|
Energy
|
2560Wh
|
|
Series or Parallel Connection
|
8S1P
|
|
Maximum Charge Current
|
100A
|
|
Standard Charging
|
Charging Current 0.2C Until 57.6V
|
|
Battery Pack Charging Cut-off Voltage
|
28.8V
|
|
Battery Pack Discharge Cut-off vo Voltage
|
21.6V
|
|
Cell Charging Cut-off Voltage
|
3.65
|
|
Dimensions (L x W x H)
|
330x482x177mm
|
|
Weight
|
30KG with wooden packing
|
|
Communication Interface
|
RS232/RS485/CAN
|
|
Case Material
|
Metal
|
|
Discharge Temperature
|
-20 to 60ºC (-4 to 140 ºF)
|
|
Charge Temperature
|
0 to 45ºC (32 to 113 ºF)
|
