Quick Details
-
Brand Name:
-
Wiliyoung
-
Model Number:
-
523450
-
Battery Size:
-
5.2*34*50mm
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
0.05kg
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
0.5C
-
Type:
-
Li-ion Polymer
-
Voltage:
-
3.7v
-
Capacity:
-
1000mAh
-
Cycle life:
-
500 Times
-
Max Charge Current:
-
1C
-
Max discharge current:
-
1C
-
Discharge Cut-off Voltage:
-
2.75V/3.0V
-
Protection:
-
Over charge,over discharge,over voltage,short circuit
-
OEM/ODM:
-
Accepatable
-
Apllication:
-
digital devices, intelligent wearable devices, digital medical devices
-
Warranty:
-
12months
-
Certification:
-
CB, CE, UI1642, BIS, KC
Quick Details
-
Storage Type:
-
dry and cool
-
Anode Material:
-
LCO
-
Application:
-
Toys, Home Appliances, Consumer Electronics
-
Brand Name:
-
Wiliyoung
-
Model Number:
-
523450
-
Battery Size:
-
5.2*34*50mm
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
0.05kg
-
The charging ratio:
-
0.5C
-
The discharge rate:
-
0.5C
-
Type:
-
Li-ion Polymer
-
Voltage:
-
3.7v
-
Capacity:
-
1000mAh
-
Cycle life:
-
500 Times
-
Max Charge Current:
-
1C
-
Max discharge current:
-
1C
-
Discharge Cut-off Voltage:
-
2.75V/3.0V
-
Protection:
-
Over charge,over discharge,over voltage,short circuit
-
OEM/ODM:
-
Accepatable
-
Apllication:
-
digital devices, intelligent wearable devices, digital medical devices
-
Warranty:
-
12months
-
Certification:
-
CB, CE, UI1642, BIS, KC
Specification
|
Basic Information
|
|
|
|
Dimension
|
5.2*34*50mm
|
|
|
Nominal capacity
|
1000mAh
|
|
|
Power
|
3.7Wh
|
|
|
Charge voltage
|
4.2V
|
|
|
Nominal voltage
|
3.7V
|
|
|
Full-charge voltage
|
4.2v
|
|
|
Ship out volatge
|
3.7-4.1v
|
|
|
Battery Specification
|
|
|
|
Standard charge
|
0.5C
|
|
|
Max charge
|
1.0C
|
|
|
Standard discharge current
|
0.5C
|
|
|
Max Standard discharge current
|
1.0C
|
|
|
Discharge cut-off voltage
|
2.75V or 3.0V
|
|
|
Charge temperature
|
0℃~45℃
|
|
|
Discharge temperature
|
-10℃~60℃
|
|
|
Storage temperature
|
-10℃~45℃
|
|
|
Battery recyle time
|
500 times
|
|
|
Warranty
|
12 Months
|
|
|
Certifications
|
UL,KC,CE,BIC,ROHS,etc
|
|
Protection
|
Built-in chips provide protection for over charge, over discharge, over voltage, short circuit and high temperture.
|
|
Charging method
|
Charge with a constant current of 0.5c to 4.2V. then charge with constant voltage 4.2v till the charge current is less than 0.01C
|
|
Application
|
Toys, BT devices, digital devices, intelligent wearable devices, digital medical devices, measuring instruments,and other high-tech electronic products.
|
360° Custom Services
Customized Battery Packs
Customized Connectors
Customized PCBs
Customized Sizes& Capacities
About US
Your reliable lithium battery solutions supplier.
1. Experienced R&D team since 2010.
2. 50,000,000 pcs annual production, 20 automatic production lines.
3. High popular for customized 3.7V lithium battery,.
4. Strictly QC team, testing equipment, with reliable after-sales service system.
5. Good comments, reputationand feedback from our satisfied customers.
Certifications
UI1642, IEC62133, UN38.3, MSDS, KC, CE, BIS, ROHS, TUV etc.
