Quick Details
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SevenLift
-
Model Number:
-
7LSJW
-
Type:
-
7LSJW Wheelchair Lift Elevator
-
Material:
-
High-duty Stainless Steel
-
Install method:
-
Directly on the floor by anchor bolts
-
Voltage:
-
2.2kw/Local Voltage
-
Control:
-
Double Controller
-
Feature:
-
Low Noise
-
Usage:
-
Higher Level
-
Email:
-
sales at sevenlift.com
-
Whatsapp/wechat:
-
8618853137587
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Free spare parts
-
Project Solution Capability:
-
3D model design
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SevenLift
-
Model Number:
-
7LSJW
-
Type:
-
7LSJW Wheelchair Lift Elevator
-
Material:
-
High-duty Stainless Steel
-
Install method:
-
Directly on the floor by anchor bolts
-
Voltage:
-
2.2kw/Local Voltage
-
Control:
-
Double Controller
-
Feature:
-
Low Noise
-
Usage:
-
Higher Level
-
Email:
-
sales at sevenlift.com
-
Whatsapp/wechat:
-
8618853137587
200kg cheap residential small home outdoor hydraulic passenger lift elevator design for home
| Model | Lifting height | Load capacity | Table size | Total size | Motor power | Material |
| 7LSJW0.3-1 | 1m | 300kg | 1.2x1m | 1.3x1.4x2.2m |
220v,2.2kw, single phase,60HZ |
With Stainless Steel |
Vertical Villa Porch Lift is a cost-effective home accessibility solution to give scooter and wheelchair users an alternative to entryway or deck steps. It designs to provide cost-effective access into or within private homes or public buildings. The porch elevator is an unenclosed vertical platform lift that can be installed directly on the floor or in a pit (check local codes - pit mounted open vertical lifts are not permissible everywhere). This durable and easy-to-use vertical platform lift is suitable for indoor or outdoor applications requiring vertical transportation up to five feet.
1.The lift won't work when the door is opening, the lift can rise if the door is completely closed. Guarantee the safety of operator.
2.Operator can operate the porch lift inside the platform.
Turn off the power and select panel or remote control.
3.Manual down value makes the platform be lowered by manual down button in case of power failure
4.The lift will be stopped at once if it touches any obstacle when going down, especially to protect the children if he enters accidentally.
5.Electromagnetic lock makes the lift won't work when the door is open, the lift can rise only when all doors are completely closed. Guarantee the safety of operator.
6.The landing door installed on each floor where operator entrance, which can prevent falling down. Standard height 900mm
7.There will be a fixed rubber ramp, for users easy coming in and out. In this way, it no need dig a pit.
8.Equipped with Anti-explosion Valve, Overflow Valve, Check Valve and Emergency Decline Valve
9.Patterned non-slip floor ensure the safety of personnel, have the role of anti-skid.
Customized P roduct ion
Lift height: 1m - 6m
Load capacity: 250kg - 350kg
Platform size: 1000*1200mm
Installation: In a pit or directly on the ground, mobile lift with wheels is also OK
Adaptable for indoor and outdoor usage, any temperature condition.
Easy installation and operation.
Emergency stop and key switch.
Separated motor pump,easily servicing and maintenance.
We promise each machine will be tested and ensure it's well work before shipment.
1) We will recommend you a suitable lift once we get your requirement.
2) We can design the 7LSJW Shandong SevenLift small hydraulic 1m wheelchair elevators stair lift home disabled handicapped as per your requirement.
3) User-friendly English manual for machine installation using and maintenance.
4) Engineers are available to your country if necessary.
5) Supply 24-hours technical assistance by email, telephone or other communication online.
