Wall Mounted Battery Solution
48V/51.2V 50-200AH
2.56-10.24KWH
2.56-10.24KWH
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
SUNARK
-
Model Number:
-
StackArk
-
Battery Size:
-
51.2V 55AH
-
Place of Origin:
-
Anhui, China
-
Weight:
-
30kg
-
The charging ratio:
-
0.7C
-
The discharge rate:
-
1C
-
Nominal Voltage:
-
51.2V~409.6V
-
Capacity Ah:
-
55AH-200AH
-
Capacity Energy:
-
2.8-22.4KWH
-
Maximum Charging Current:
-
0.7C
-
Maximum Discharging Current:
-
1C
-
BMS:
-
Built-in
-
Life Cycling (0.5C 25℃):
-
6000 cycles @ 0.5C
-
Warranty:
-
10 Year, 10YEARS
-
Certification:
-
MSDS, UN38.3, ROHS, IEC62619, CE
-
IP Class:
-
IP54
Quick Details
-
Storage Type:
-
-20°C~45°
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
SUNARK
-
Model Number:
-
StackArk
-
Battery Size:
-
51.2V 55AH
-
Place of Origin:
-
Anhui, China
-
Weight:
-
30kg
-
The charging ratio:
-
0.7C
-
The discharge rate:
-
1C
-
Nominal Voltage:
-
51.2V~409.6V
-
Capacity Ah:
-
55AH-200AH
-
Capacity Energy:
-
2.8-22.4KWH
-
Maximum Charging Current:
-
0.7C
-
Maximum Discharging Current:
-
1C
-
BMS:
-
Built-in
-
Life Cycling (0.5C 25℃):
-
6000 cycles @ 0.5C
-
Warranty:
-
10 Year, 10YEARS
-
Certification:
-
MSDS, UN38.3, ROHS, IEC62619, CE
-
IP Class:
-
IP54
Product Description
|
Model
|
StackArk-2600
|
|
|
|
|||
|
Capacity Energy
|
2.8kWh
|
|
|
|
|||
|
Capacity Ah
|
55Ah
|
|
|
|
|||
|
Suggested SOC
|
10-100%
|
|
|
|
|||
|
Usable Capacity
|
2.6kWh
|
|
|
|
|||
|
Nominal Voltage
|
51.2V
|
|
|
|
|||
|
Operation Voltage
|
44.8V – 57.6V
|
|
|
|
|||
|
Maximum Charging Current
|
35A
|
|
|
|
|||
|
Maximum Discharging Current
|
50A
|
|
|
|
|||
|
BMS
|
Robust Multi Point Monitoring BMS
|
|
|
|
|||
|
Scalable
|
Yes, Maximum 15 Packs In Parallel, 2-8 Packs in Series
|
|
|
|
|||
|
Life Cycling (0.5C 25℃)
|
6000 Cycles @ 0.5C
|
|
|
|
|||
|
Warranty
|
10 Years
|
|
|
|
|||
|
Operation Temperature
|
Chrage : 0 ~ 45℃, Dischrage : -20 ~ 45℃
|
|
|
|
|||
|
Storage Temperature
|
-20 ~ 45℃
|
|
|
|
|||
|
Net Weight
|
30kG
|
|
|
|
|||
|
Dimensions (H x W x D)
|
480 x 280 x 210 mm
|
|
|
|
|||
|
Certifications
|
MSDS, UN38.3, RoHS, IEC62619, UL, CE
|
|
|
|
|||
|
IP Grade
|
IP54
|
|
|
|
|||
|
Communication
|
RS232, RS485, CAN (Compitable with most brand inverters in market)
|
|
|
|
|||
Applications
Details Images
Compatiable Inverters
|
Type
|
Single Phase
|
3 Phase
|
Split Phase
|
||
|
Output Power
|
3-16KW
|
5-30KW
|
5-8KW
|
||
|
Output Voltage
|
220/230/240V
|
220/380V, 230/400
|
120/240V
|
||
|
Battery Type
|
Lead Acid or Lithium Ion 40-60V
|
|
|
||
Residential BESS
Wall Mounted Battery Solution
GroundArk Series
Ground Mounted Battery Solution
Voltage 51.2V
2.6-10.4KWH
2.6-10.4KWH
Stack Mounted High Voltage Battery Solution
Voltage 260-350V
8KWH-20KWH
8KWH-20KWH
Commercial & Industrial BESS
RackArk HV 100-600V 16.8kWh-25kWh
RackArk HV 100-1000V 108kWh
RackArk HV 100-1000V 108kWh
RackArk HV 100-1400V 164kWh
CubeArk-20 (690-828V 1296kWh)
CubeArk-40 (690-828V 2592kWh)
