Quick Details
-
Model Number:
-
NP-MK
-
Name:
-
Metal Power Distribution Box 3 Phase
-
Usage:
-
Safe Power Distribution
-
Rated Voltage:
-
110/220V 50/60Hz
-
Rated Current:
-
63A
-
Operation:
-
Manual,APP Remote Control,Auto Re-close
-
Power Consumption:
-
≤ 2W
-
Output Circuit:
-
4/6/8/12 ways (customized)
-
Residual Operating Current:
-
1-10mA
-
Over-voltage Protection:
-
220V:270V~275V 110V:150-155V
-
Under-voltage Protection:
-
220V:270V~275V 110V:150-155V
Quick Details
-
Current:
-
63A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Neider
-
Model Number:
-
NP-MK
-
Name:
-
Metal Power Distribution Box 3 Phase
-
Usage:
-
Safe Power Distribution
-
Rated Voltage:
-
110/220V 50/60Hz
-
Rated Current:
-
63A
-
Operation:
-
Manual,APP Remote Control,Auto Re-close
-
Power Consumption:
-
≤ 2W
-
Output Circuit:
-
4/6/8/12 ways (customized)
-
Residual Operating Current:
-
1-10mA
-
Over-voltage Protection:
-
220V:270V~275V 110V:150-155V
-
Under-voltage Protection:
-
220V:270V~275V 110V:150-155V
What Is Smart Safety Distribution Box?
T
he NP-MK Smart Safety Distribution Box is a new type of distribution box that has undergone hundreds of thousands of repeated experiments and more than a decade of dedicated research and development. This distribution box adopts intelligent monitoring and microsecond-level rapid response technology to ensure the absolute safety of the output circuits. It not only completely eliminates the occurrence of accidental electric shock to the human body but also prevents sparks from occurr
ing during short circuits, thereby preventing safety incidents such as fires and explosions.
|
NP-MK |
|
|
≤ 2W |
|
|
220V :270V~275V 110V:150-155V |
|
|
220V:150V~155V 110V:80-85V |
|
|
Over-current Protection |
1.2In |
|
1S |
|
|
Short-current Protection |
3 In |
|
Operate Time of Protection |
≤1us |
|
Lightning Resistance |
The device is capable of withstanding a combination wave of 1.2/50us (8/20us) between L-N, with no false triggering at 2KV and no damage at 6KV. It can also disconnect the load within 1us and automatically restore power after lightning cessation. |
|
Installation |
Built-in or wall-mounted |
|
Shell Color |
White (customized) |
|
Dimension |
|
|
Shell Material |
1. Q: What is your MOQ?
A: Our MOQ is 1 piece.
2. Q: what is your delivery time?
A: It will be within 3 working days if in stock. If no stock it depends on your quantity.
3. Q: What is your warranty ?
A: The warranty period of our products is 2 years.
4. Q: How about inspection?
A: We have the whole inspection system from raw material to end products, including transient test, delay test, mechanical life test and so on.
5. Q: Is OEM and ODM OK for you?
A: Yes, we can do both OEM and ODM. We have the professional enginer team which can design and develop the mold to arrive different customers’ requirement.
6. Q: May I become your Agent / Dealer?
A: Welcome! But please let us know your country/area fisrt, we will have a check and then talk about this. If you want any other kind of cooperation, do not hesitate to contact us.
