Quick Details
-
Rolling thinckness:
-
0.3-0.8mm
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RFM
-
Voltage:
-
380V 50Hz, 3Phases
-
Dimension(L*W*H):
-
7.7*1.65*1.55
-
Weight:
-
6.2 kg
-
Warranty:
-
1year
-
name:
-
feixiang feitian square tube roll forming machine
-
Frame:
-
350#steel
-
roller:
-
45#steel
-
Size:
-
as costomer's need
-
advantage:
-
No noise,no shake
-
guarantee:
-
1year for electric welded pipe
-
level and measure:
-
fully automatic electric welded pipe
-
certificate:
-
CE,ISO,TUV
-
usage:
-
for normal life
-
material:
-
steel
Quick Details
-
Type:
-
Tile Forming Machine
-
Tile Type:
-
Steel
-
Production Capacity:
-
3-6m/minute
-
Rolling thinckness:
-
0.3-0.8mm
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
RFM
-
Voltage:
-
380V 50Hz, 3Phases
-
Dimension(L*W*H):
-
7.7*1.65*1.55
-
Weight:
-
6.2 kg
-
Warranty:
-
1year
-
name:
-
feixiang feitian square tube roll forming machine
-
Frame:
-
350#steel
-
roller:
-
45#steel
-
Size:
-
as costomer's need
-
advantage:
-
No noise,no shake
-
guarantee:
-
1year for electric welded pipe
-
level and measure:
-
fully automatic electric welded pipe
-
certificate:
-
CE,ISO,TUV
-
usage:
-
for normal life
-
material:
-
steel
feixiang feitian square tube roll forming machine
Advantage
♥ Specialize in all kinds of roll forming machine as a professional manufacturer.
♥ Rich experience of 15 years to export to more than 40 countries in this industry.
♥ Best price,quality,service and most quickly delivery.
1. Picture
2. Description
| 1. | Name | feixiang feitian square tube roll forming machine |
| 2. | Raw Materil |
Hot or cold-rolled low-carbon steel ( ST-37 ) , low alloy steel strip |
| 3. | Steel coil thickness | 1.2 ~4.0mm |
| 4. | Steel coil Width | 100 ~400mm |
| 5. | Steel coil |
I.D. : φ 500 ~φ 550mm O.D.: φ 1000 ~φ 1500mm Maximum weight of steel strip:5000kgs |
| 6. | Steel coi l Request | As perYB189-64(tube strip) |
| 7. | finished product Circular pipe |
Diameter : φ32 ~ φ127mm square pipe:25*25 ~ 100*100 Wall thickness : 1.2 ~ 4.0mm square pipe:1.2 ~ 3.0mm |
| 8. | The administer standard of product : |
GB/T3091-93 ; GB/T13973-92 ; ASTMA53 ; |
| 9. | Milling speed of machine unit |
20 ~ 60 m/min |
3. Working Flow
decoiler → Shear & butt-welder → horizontal accumulation → feeding and leveling → roll forming → high-frequency welding → deburring → cooling → sizing → straightening → fixed length cutting → run-out table
4.Auto Working Line
Our products are used widely in various fields: industrial factory, civilian building, warehouse,
easy steel building, manufacturing, construction and have features such as nice appearance and
durable. The colored steel tiles produced by this machine look beautiful ,elegant and noble.They are widely used as the roof of garden,factory,hotel,exhibition center and villa,etc.
Our company is located in Botou City of Hebei Province, next to 104 National Highway. We are specialized in producing different types of automatic cold roll forming machines, such as stone-coated roofing tile line, Light keel roll forming machine, shutter and door frame roll forming machine and automatic partial adjustment C purlin machine.
At present, steel construction is widely used and in great demand. In order to meet the increasing market demand for roll forming machines in different shapes of metal sheets, we have made great investment to improve flawless techniques. Our professional technicians and skilled workers ensure high quality products for our customers with perfect quality management and testing systems.
The success of our company comes from success and development of our customers. We bear this in mind in the whole process from design, product research and development to after sales service. What we value is reputation and service, what we sell is quality and technology.
We warmly welcome old and new clients from all over the world to visit our company and establish business relationships with us. We do believe our mutual cooperation will create a brilliant future.
If you are interested in our products,and want to know more details,
you can click the link below and send us your inquiry.
we will reply immediately.
