Quick Details
-
Memory Type:
-
DDR4
-
Graphics Card Type:
-
Integrated
-
CPU Type:
-
Celeron
-
Chipset:
-
Celeron
-
Socket Type:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Processor:
-
Celeron J4125
-
Memory:
-
1*SODIMM
-
Storage:
-
1*SATA3.0 1*MSATA
-
Expansion Interface:
-
1*MINI PCIE for WiFi+Bluetooth or 4G LTE
-
BIOS:
-
AMI UEFI BIOS
-
OS support:
-
Win10, Linux
-
Parallel:
-
1*LPT/2*15PIN/2.0MM
-
GPIO:
-
1*GPIO head pin
-
Multiple Display:
-
Support dual monitor display
-
Temperature:
-
Operation: -10℃~60℃, Storage: -20℃~70℃
Quick Details
-
Maximum Ram Capacity:
-
16GB
-
Application:
-
Desktop
-
Form Factor:
-
THIN MINI ITX
-
Memory Type:
-
DDR4
-
Graphics Card Type:
-
Integrated
-
CPU Type:
-
Celeron
-
Chipset:
-
Celeron
-
Socket Type:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Processor:
-
Celeron J4125
-
Memory:
-
1*SODIMM
-
Storage:
-
1*SATA3.0 1*MSATA
-
Expansion Interface:
-
1*MINI PCIE for WiFi+Bluetooth or 4G LTE
-
BIOS:
-
AMI UEFI BIOS
-
OS support:
-
Win10, Linux
-
Parallel:
-
1*LPT/2*15PIN/2.0MM
-
GPIO:
-
1*GPIO head pin
-
Multiple Display:
-
Support dual monitor display
-
Temperature:
-
Operation: -10℃~60℃, Storage: -20℃~70℃
Product Description
|
Processor performance
|
|
|
|
Processor
|
Intel® Celeron J4125 Quad core 2.0GHz Turbo boost 2.6GHz
|
|
|
Chipset
|
Intel® SOC, TDP 10W
|
|
|
Memory
|
1*SODIMM, 4GB upgrade to 16GB DDR4-2666
|
|
|
Storage
|
1*SATA3.0
1*MSATA |
|
|
Expansion Interface
|
1*MINI PCIE for WiFi+Bluetooth or 4G LTE
|
|
|
BIOS
|
AMI UEFI BIOS
|
|
|
OS support
|
Windows 10, Linux
|
|
|
I/O Interface
|
|
|
|
Ethernet
|
2*Gigabit Ethernet Connector, RJ45
|
|
|
RS232
|
2*RS232 by default, 4*RS232+2*RS485 optional
|
|
|
USB
|
2*USB 3.0, 4*USB 2.0（2*5PIN/2.0MM）
|
|
|
PS/2
|
1*PS/2/1*6PIN/2.0MM
|
|
|
Audio
|
1*Audio, 1*MIC,1*Audio (2*5PIN/2.54MM), 1*AMP (1*4PIN/2.0MM)
|
|
|
Parallel
|
1*LPT/2*15PIN/2.0MM
|
|
|
GPIO
|
1*GPIO head pin
|
|
|
Display
|
|
|
|
Display Interface
|
1*HDMI: 1920*1080 1*JHDMI/2*8PIN/2.0MM（HDMI either-or JHDMI）
1*VGA，1*JVGA/1*12PIN/2.0MM（VGA either-or JVGA） 1*LVDS/2*15PIN/2.0MM 1*EDP/2*15PIN/2.0MM （LVDS either-or EDP） |
|
|
Multiple Display
|
Support dual monitor display
|
|
|
Mechanical & Environment
|
|
|
|
Function
|
Auto power on, PXE, Watchdog
|
|
|
Dimension
|
170*170mm
|
|
|
Power Input
|
DC 12V（5.5*2.5MM） ATX 2*2PIN(MX4.2)
|
|
|
Temperature
|
Operation: -10℃~60℃, Storage: -20℃~70℃
|
|
|
Relative Humidity
|
Operation: 10%~90%, Storage: 5%~95%, non-condensing
|
|
