you should make sure peak temperature at this range.
Therecommended sintering temperature is 1500C.
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
3D PRO
-
Material:
-
zirconia
-
Brand Name:
-
Glorious
-
Product name:
-
3DPro Zirconia Blocks
-
Size:
-
98/95/89MM
-
Thickness:
-
10/12/14/16/18/20/22/25/30mm
-
Translucency:
-
43%-57%
-
hardness:
-
650-1350mpa
-
Color:
-
white vita16 BL1-BL4
-
Packing:
-
1piece/box
-
Usage:
-
98 milling open systemetc
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Place of Origin:
-
Shandong, China
-
Model Number:
-
3D PRO
-
Material:
-
zirconia
-
Brand Name:
-
Glorious
-
Product name:
-
3DPro Zirconia Blocks
-
Size:
-
98/95/89MM
-
Thickness:
-
10/12/14/16/18/20/22/25/30mm
-
Translucency:
-
43%-57%
-
hardness:
-
650-1350mpa
-
Color:
-
white vita16 BL1-BL4
-
Packing:
-
1piece/box
-
Usage:
-
98 milling open systemetc
Product paramenters
|
Model Number
|
3DPro
|
|
Material
|
zirconia
|
|
Thickness
|
10/12/14/16/18/20/22/25/30mm
|
|
Translucency
|
43%-57%
|
|
Hardness
|
650-1350mpa
|
|
Colors
|
White Vita16 BL1 BL2 BL3 BL4
|
|
Features
|
Multi-layer
|
|
OEM
|
Provide OEM
|
|
Package
|
1piece /box
|
Sintering Chart
Recommended sintering curve(3D-pro)
Recommended sintering curve(3D-pro)
Sintering temperature of 3D-pro is from 1480℃ to 1530C，
Product Introduction
|
Components
|
3D-pro
|
|
ZrO2+HfO2+Y2O3
|
≥99%
|
|
Y2O3
|
4.5%-10%
|
|
Al2O3
|
＜0.15%
|
|
Other Oxides
|
＜0.5%
|
|
Light transmittance(1.0±0.02mm)
|
＜49%
|
|
Pro- sintering Density
|
3.15±0.05g.cm-3
|
|
Post-sintering Density
|
6.07±0.02g.cm-3
|
|
CTE (25-500℃)
|
10.5k-1
|
|
Pro-sinteringFlexural strength
|
＞650mpa
|
|
Post-sintering Chemical solubility
|
＜100μg.cm-2
|
|
Cytotoxicity
|
0 Level
|
|
Radioactivity
|
＜0.1Bq.g-1
|
|
Sintering temperature
|
1450-1510℃
|
|
Thickness
|
10/12/14/16/18/20/22/25
|
|
Features
|
crowns and bridges
|
|
multilayer21color
|
A0(white) A1,A2,A3,A3.5,A4, B1,B2,B3,B4, C1,C2,C3,C4, D2,D3,D4, BL1,BL2,BL3,BL4
|
Our Zirconia Block be made of the biological zirconia powder with isostatic pressing method and keep processing in machinecenter.
We can do the zirconia block according to the clients the requirement. HT Zr -- Normal translucent zirconia, applied for crown and bridges.
ST Zr -- Super translucent zirconia, applied for crown and bridges especially for full contour crown and bridges.
ST Zr -- Super translucent zirconia, applied for crown and bridges especially for full contour crown and bridges.
Details Images
Multi-layer zirconia dental blank that has a gradual change in chroma and translucency though a thicness after sintering.
We choose the best zirconia powder and utilize a cold isostatic pressing system to from shapes
Zirconia block
