Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vstarcam
-
Model Number:
-
CB71
-
APP:
-
OK CAM
-
Resolution:
-
2MP,1080P
-
Lens:
-
3.6mm HD Lens
-
Power Supply:
-
DC 5V
-
Network:
-
Wifi 2.4Ghz
-
Night vision:
-
Auto IR-CUT
-
Storage:
-
Support Cloud Storage/TF Card( Max 256GB)
-
Battery:
-
1500mAh
-
Audio:
-
Two-way Audio Intercom
Quick Details
-
Special Features:
-
NIGHT VISION, Motion Detection, Sound Detection, Two-way Audio, Low Power
-
Function:
-
Two-way Audio, Abnormal sound detection, RESET, Built-in Mic, NIGHT VISION, Wide Angle
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Vstarcam
-
Model Number:
-
CB71
-
APP:
-
OK CAM
-
Resolution:
-
2MP,1080P
-
Lens:
-
3.6mm HD Lens
-
Power Supply:
-
DC 5V
-
Network:
-
Wifi 2.4Ghz
-
Night vision:
-
Auto IR-CUT
-
Storage:
-
Support Cloud Storage/TF Card( Max 256GB)
-
Battery:
-
1500mAh
-
Audio:
-
Two-way Audio Intercom
Products Description
Product Paramenters
|
Model #
|
|
CB71
|
|
|
|||
|
APP
|
|
OKCAM
|
|
|
|||
|
Operation system
|
|
Embedded Linux OS
|
|
|
|||
|
Online visitor
|
|
Support 4 visitors at the same time
|
|
|
|||
|
Image sensor
|
|
Progressive Scan CMOS
|
|
|
|||
|
Minimum Illumination
|
|
0.1-0.5Lux(color mode), 0 Lux(B&W mode)
|
|
|
|||
|
Lens
|
|
2.8mm
|
|
|
|||
|
View Angle
|
|
145˚(Diagonal)
|
|
|
|||
|
Night vision
|
|
4 pcs 940nm 14mil patch IR LED, IR irradiation distance: 3m
|
|
|
|||
|
Video Encode format
|
|
H.264+/H.264 main profile@level:4.0/Motion-JPEG/JPEG
|
|
|
|||
|
Video Streams
|
|
Main stream:1920*1080@30fps Sub stream:640*360@25fps/30fps
|
|
|
|||
|
Video Bit Rate/Max Fps
|
|
128～4096kbps/30pfs
|
|
|
|||
|
Video Image adjustment
|
|
Brightness and contrast can be adjusted
|
|
|
|||
|
Audio Input
|
|
Built-in－38±5dB microphone
|
|
|
|||
|
Audio Output
|
|
Built-in 8Ω1W speaker
|
|
|
|||
|
Audio Sampling frequency /Bit width
|
|
8KHz/16bit
|
|
|
|||
|
Compression standard /code rate
|
|
ADPCM/32kbps
|
|
|
|||
|
Network Protocols
|
|
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,P2P etc
|
|
|
|||
|
Wireless LAN
|
|
IEEE802.11b/g/n, Supports AP mode
|
|
|
|||
|
Wireless LAN Frequency
|
|
2.4~ 2.4835GHz
|
|
|
|||
|
Wireless LAN security
|
|
64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
|
|
|
|||
|
Storage
|
|
TF Push-push socket,Maximum support 256GB,Cloud storage
|
|
|
|||
|
Alarm Trigger
|
|
Motion detection
|
|
|
|||
|
Battery Capacity
|
|
1500mah
|
|
|
|||
|
Rated voltage
|
|
DC5V±5%@Micro USB
|
|
|
|||
|
Power consumption
|
|
Rated power: 1.3W (with infrared lights on)
|
|
|
|||
|
Operating condition
|
|
Temperature:-10～50℃,humidity:＜90%
|
|
|
|||
|
Weight
|
|
Net: 60g Gross：210g(Note: in kind prevail)
|
|
|
|||
|
Package size
|
|
133x104x60mm (L×W×H)
|
|
|
|||
