Hydraulic outriggers lift articulated boom trailer mounted cherry picker for sale boom lift

Hydraulic outriggers lift articulated boom trailer mounted cherry picker for sale boom lift

FOB Reference Price: Get Latest Price

≥1 Sets

US $4805.56

≥6 Sets

US $4613.33

≥16 Sets

US $4325

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Power:: 24V/2*0.5KW

Min. Lifting Height:: 1020mm

Table Size:: 1400mm*760mm

Overall Dimensions:: 1520mm*760mm

Weight:: 994 kg

Marketing Type:: Other

Warranty of core components:: Other

battery charger:: 24V15A

storage battery:: 2*12V100Ah

wheel size:: 305*100mm

driving mode:: Non marking rubber tire

drive /brake:: Double rear wheels

max operating angle:: 1.5°/2.5°

max climbing capacity:: 25%(14°)

lifting /falling time:: 36/37s

driving motor:: 24V/2*0.5KW

lifting motor:: 24V/2.2KW/2.6CC

Quick Details

Warranty:: 1.5 years

Place of Origin:: Jiangsu, China

Brand Name:: ShenHu

Power:: 24V/2*0.5KW

Min. Lifting Height:: 1020mm

Table Size:: 1400mm*760mm

Overall Dimensions:: 1520mm*760mm

Weight:: 994 kg

Marketing Type:: Other

Warranty of core components:: Other

battery charger:: 24V15A

storage battery:: 2*12V100Ah

wheel size:: 305*100mm

driving mode:: Non marking rubber tire

drive /brake:: Double rear wheels

max operating angle:: 1.5°/2.5°

max climbing capacity:: 25%(14°)

lifting /falling time:: 36/37s

driving motor:: 24V/2*0.5KW

lifting motor:: 24V/2.2KW/2.6CC

Products Description

item	0607
MIX WORKING HEIGHT	8m
MAX PLATFORM HEIGHT	6m
MIN PLATFORM HEIGHT	1020m
WORK PLATFORM LENGTH	1400mm
WORK PLATFORM WIDTH	760mm
PLATFORM EXTENSION SIZE	600mm
WHOLE MACHINE HEIGHT (FENCE EXPANSION)	2160mm
WHOLE MACHINE HEIGHT (FENCE FOLDED)	1520mm
WHOLE MACHINE LENGHT	1520mm
WHOLE MACHINE WIDTH	760mm
RATED LOAD	230kg
EXTENDED PLATFORM SAFE WORKING LOAD	100kg
MAX WORKERS	2
DRIVING SPEED (FOLDED MODE)	4Km/h
DRIVING SPEED (LIFTING)	0.45Km/h
LIFTING MOTOR	24V/2.2KW/2.6CC
DRIVING MOTOR	24V/2×0.5KW
LIFTING /FALLING TIME	36/37s
MAX CLIMBING CAPACITY	25%(14°)
MAX OPERATING ANGLE	1.5°/2.5°
DRIVE /BRAKE	Double rear wheels
DRIVING MODE	Non marking rubber tire
WHEEL SIZE	305×100mm
STORAGE BATTERY	2×12V100Ah
BATTERY CHARGER	24V15A
WHOLE MACHINE WEIGHT	994kg

Details Images

Seamless rubber tires

The diameter is 305mm, the tire width is 100mm, the tire is larger, the obstacle crossing ability is stronger, the climbing ability is 25% (14°), and the passability is excellent.

Big tires make walking more stable and comfortable driving experience.
