Quick Details
-
Model Number:
-
WS55CON-E
-
Weight:
-
32KG
-
Panel Type:
-
LCD
-
Packing Dimension:
-
1395mm*90 1mm*190mm,42KG
-
Product Dimension:
-
1273.4mm*773mm*92.4 mm
-
Material:
-
Aluminum Alloy Frame+4mm tempered glass
-
Touch points:
-
infrared 20 touch points
-
response time:
-
6MS
-
Life Time:
-
50000H
-
Operating system:
-
Android 11
-
Accessory:
-
Wall Mounted Bracket,write pen,long pointer,remote control...
-
Installation:
-
wall mounted/moving stand
-
Certificates:
-
KC ISO9001 ISO45001 ISO14001 CE FCC ROHS
-
Warranty:
-
standard 1 year
Quick Details
-
Panel Size:
-
55inches
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Whale Screens
-
Model Number:
-
WS55CON-E
-
Weight:
-
32KG
-
Panel Type:
-
LCD
-
Packing Dimension:
-
1395mm*90 1mm*190mm,42KG
-
Product Dimension:
-
1273.4mm*773mm*92.4 mm
-
Material:
-
Aluminum Alloy Frame+4mm tempered glass
-
Touch points:
-
infrared 20 touch points
-
response time:
-
6MS
-
Life Time:
-
50000H
-
Operating system:
-
Android 11
-
Accessory:
-
Wall Mounted Bracket,write pen,long pointer,remote control...
-
Installation:
-
wall mounted/moving stand
-
Certificates:
-
KC ISO9001 ISO45001 ISO14001 CE FCC ROHS
-
Warranty:
-
standard 1 year
|
Dual system
|
|
|
|
Windows 7/10 operating system
|
CPU option: Intel Core i3/i5/i7
Memory stick optional: 4G/8G/16G/32G
SSD optional: 128G/256G/512G/1024G
|
|
|
Android 11/13 operating system
|
Motherboard: 4-core/8-core
RAM: 4G/8G/16G
ROM: 32G/64G/128G/256G
|
|
|
Liquid crystal screen
|
|
|
|
Sizes
|
55/65/75/85/98/110 inch
|
|
|
OC Brands
|
BOE / TCL / AUO
|
|
|
Resolution
|
3840*2160
|
|
|
Luminance
|
≥500cd/m²
|
|
|
Screen contrast
|
4000:1
|
|
|
Response time
|
6ms
|
|
|
Pixel Pitch
|
0.4296 mm x 0.4296mm (H×V)
|
|
|
Frame rate
|
60 Hz
|
|
|
Viewing Angle
|
178°(H) / 178°(V)
|
|
|
Colour saturation (x% NTSC)
|
72 %
|
|
|
Colour Degree
|
1.07B(8bit)
|
|
|
Lifetime
|
50,000 hrs
|
|
|
Voltage
|
100 V ~ 240 V/AC, 50/60 Hz
|
|
|
Accompaniment Power
|
8Ω/10W*2
|
|
|
Front Interface
|
Switch button*1
USB (shared)*3
Type-c USB*1
HDMI IN*1
TOUCH_OUT*1
|
|
|
Environmental factors
|
|
|
|
Operating Temperature
|
0℃ ~ 40℃
|
|
|
Storage Temperature
|
-10℃ ~ 60℃
|
|
|
Operating Humidity
|
20% ~ 80%
|
|
|
Storage Humidity
|
10% ~ 60%
|
|
|
Maximum use time (hours*day)
|
18Hours*7days
|
|
|
Structure（75inch）
|
|
|
|
Net weight
|
54Kg±1.5Kg
|
|
|
Gross Weight
|
60Kg±1.5Kg(Heavy duty carton)
|
|
|
Bare unit size
|
1710mm*1037.6mm*89.6mm
|
|
|
Package Size
|
1850mm*1150mm*205mm(Heavy duty carton)
|
|
|
Shell Material
|
Aluminium profiles/sheet metal
|
|
|
Shell colour
|
Black/Grey/Silver
|
|
|
Accessories
|
Wifi Antenna*4
Magnetic Pen*2
Remote Control*1
Instruction Manual
Certificate of Conformity/Warranty Card
1.5m Power Cord
Wall mounting bracket
|
|
|
Touch parameters
|
|
|
|
Touch Specifications
|
Infrared touch frame
|
|
|
Glass specification
|
Plain glass/anti-glare toughened glass optional
|
|
|
Touch precision
|
90% centre area accuracy ±1mm, 10% edge area accuracy ±3mm
|
|
|
Touch Diameter
|
≥3mm
|
|
|
Input Method
|
Finger or pen
|
|
|
Theoretical clicks
|
Unlimited
|
|
1) Are you a factory or a trading company? What is the minimum order quantity for touch screens?
A: Yes, we are manufacturer direct sales and have some inventory items, You can order 1 piece for testing.
2) What is the delivery time? Where will you ship the touch screen to?
A: Delivery time is usually around 10 days for quantity 5 for example. In addition our factory is located in Baoan District, Shenzhen, if you have a freight forwardel in Shenzhen or Guangzhou, we can assist in shipping the products to your freight
forwarder.
3) Can you provide OEM&ODM services for touch screens?
A: Of course, including software, packaging, product logos, etc. For more details. please consult customer service,
4) What is the warranty period for touch screens?
A: Generally, it takes one year, We have a professional after-sales service team. and specific details can be consulted with customer service.
5)How do you ensure the quality of the touch screen?
A: Our products comply with the ISO9001 quality system and CE/FCC/ROHS standards. All of our products undergo strict quality control inspections during the production process. Especially for exported products, a 72 hour aging test is
required to ensure that there are no issues before shipment.
6) How do you arrange the transportation of touch screens?
A: lf the sample order is recommended to be shipped by express delivery (7-10 days) or air freight (10-15 days), and if mass production is recommended, sea freight is more favorable, Please consult customer service for more details!
