Quick Details
-
Model Number:
-
w315
-
Product Name:
-
dj equipment beats audio disco loudspeaker outdoor high end speaker 15
-
Material:
-
high quality plywood
-
finish:
-
waterproof Black color
-
Components:
-
LF:1x15" ,MF:2x8" , HF:4x1"
-
type:
-
Longbow 15inch three way line array
-
Rated Power:
-
LF:500W , MF:400W,HF:240W
-
Peak Power(PEAK):
-
LF:1000W , MF:800W,HF:480W
-
SPLmax / 1 m:
-
135dB
-
Connectors:
-
SPEAKON NL8*2 Neutrik
-
system:
-
A large scale three way line array enclosure
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
oem
-
Model Number:
-
w315
-
Product Name:
-
dj equipment beats audio disco loudspeaker outdoor high end speaker 15
-
Material:
-
high quality plywood
-
finish:
-
waterproof Black color
-
Components:
-
LF:1x15" ,MF:2x8" , HF:4x1"
-
type:
-
Longbow 15inch three way line array
-
Rated Power:
-
LF:500W , MF:400W,HF:240W
-
Peak Power(PEAK):
-
LF:1000W , MF:800W,HF:480W
-
SPLmax / 1 m:
-
135dB
-
Connectors:
-
SPEAKON NL8*2 Neutrik
-
system:
-
A large scale three way line array enclosure
Specification
W315 Longbow 15inch three way line array
Longbow 15inch three way line array
Components : LF:1x15” ,MF:2x8” , HF:4x1”
Frequency Response: 60Hz - 18kHz(±3dB)
Sensitivity (1W/1M) HF:109dB MF:106dB LF:103dB
Maximum Peak SPL: 135dB
Rated Power(RMS) : LF:500W , MF:400W,HF:240W
Peak Power(PEAK): LF:1000W , MF:800W,HF:480W
Impedance(Ohm) HF:8 Ohm; MF:8 Ohm; LF:8 Ohm
Crossover mode
Dispersion Angle(-6dB): 90H x 0-6V (-6dB); 120H x 0-6V (-12dB)
Connectors :2xNL8 Speakon
Riggings: Standard Rigging same as original
Enclosure Material: high quality plywood with waterproof dark grey or black coating
Dimensions (mm): 1314*490*755 ,Net weight:123kg
Specification:
W315 is professional, three-way, full-range loudspeakers, ideal for various installed sound reinforcement applications requiring
high power in a stylish enclosure. All models feature a 3-inch voice coil compression driver combined with high-output woofers to
deliver exceptional full bandwidth reproduction.
More Features
1). Compact, high performance three-way line array enclosure
2). High power - Rated Power(RMS) : LF:500W , MF:400W,HF:240W
Peak Power(PEAK): LF:1000W , MF:800W,HF:480W
3). Superior bass impact - all horn design
4). Fast, integral rigging system with variable splay angles from 0° to 7.5°
5). Common grid may be used for flying or ground stacking
Ideal applications for the 15‘’ Longbow line array loudspeaker system
Live Sound Reinforcement
Outdoor concerts, stadiums and indoor arenas
Fixed Installations
it brings a new level of performance to the most demanding sound reinforcement applications such as outdoor festivals, sports stadiums and the largest arenas.
Specification:
W315 is professional, three-way, full-range loudspeakers, ideal for various installed sound reinforcement applications requiring
high power in a stylish enclosure. All models feature a 3-inch voice coil compression driver combined with high-output woofers to
deliver exceptional full bandwidth reproduction.
More Features
1). Compact, high performance three-way line array enclosure
2). High power - Rated Power(RMS) : LF:500W , MF:400W,HF:240W
Peak Power(PEAK): LF:1000W , MF:800W,HF:480W
3). Superior bass impact - all horn design
4). Fast, integral rigging system with variable splay angles from 0° to 7.5°
5). Common grid may be used for flying or ground stacking
Ideal applications for the 15‘’ Longbow line array loudspeaker system
Live Sound Reinforcement
Outdoor concerts, stadiums and indoor arenas
Fixed Installations
it brings a new level of performance to the most demanding sound reinforcement applications such as outdoor festivals, sports stadiums and the largest arenas.
Product Description
More about US:
Our Main Products:
Line Array, Subwoofer, Stage Monitor, PA Speaker, Amplifier, Active Speaker, Active Line Array, Passive Speaker, Bass Bin, Coaxial Monitor ,digital power amplifier, fp power amplifier series, amplifier module(amp board plate). about crossover frequency , we have pro audio frequency divider passive filter network crossover and and also have dsp processor speaker management system. and also quick release pins and all kind of rigging for speakers and line array systems.we manufacture top end quality and economic class to meet different market customer needs.we also produce speaker subwoofer rain cover protective speaker covers and subwoofer dolly , flying frame bumper for line array, About the packing, can use carton packing or flightcase(roadcase) packing.
About the shipment: shipment by air,by express, by sea, by railway to door, and also you can pick up from us.
if you have your agent's warehouse in China, we can ship to your warehouse.
Customization: We accept all customization request from you.Welcome to contact us.
