Quick Details
-
Brand Name:
-
C9200L-24P-4G-E
-
Model Number:
-
C9200L-24P-4G-E
-
Place of Origin:
-
China
-
Product Name:
-
C9200L-24P-4G-E
-
Dimensions (W x D x H):
-
4.4X44.5X28.8CM
-
Weight:
-
15KG
-
Warranty:
-
1 Year
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
56Gbps, 56 Gbps
-
Brand Name:
-
C9200L-24P-4G-E
-
Model Number:
-
C9200L-24P-4G-E
-
Place of Origin:
-
China
-
Product Name:
-
C9200L-24P-4G-E
-
Dimensions (W x D x H):
-
4.4X44.5X28.8CM
-
Weight:
-
15KG
-
Warranty:
-
1 Year
Product Description
Specification
|
Model
|
C9200L-24P-4G-E
|
|
Uplink configuration
|
4x 1G fixed uplinks
|
|
Downlinks total 10/100/1000 or PoE+ copper ports
|
24 ports full Powe
|
|
Transmission Rate
|
10/100/1000Mbps
|
|
Software
|
Network Essentials
|
|
Communication Mode
|
Full-Duplex & Half-Duplex
|
|
Switch Capacity
|
56 Gbps
|
|
Place of Origin
|
China
|
|
|
Beijing
|
|
Warranty
|
1 Year
|
|
Chassis Dimensions
|
1.73 x 17.5 x 11.3 in
4.4 x 44.5 x 28.8 cm |
|
Weight
|
15. Kg
|
Product Description
Up to 24 ports of full Power over Ethernet Plus (PoE+) capability
Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
Flexible downlink options with data
Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
Advanced network monitoring using Full Flexible NetFlow
Cisc0 Software-Defined Access (SD-Access):
Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisc0 Identity Services Engine
(ISE)
Resiliency with Field-Replaceable Units (FRU) and redundant power supply, fans, and modular uplinks
Flexible downlink options with data
Operational efficiency with optional backplane stacking, supporting stacking bandwidth up to 160 Gbps
UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
Layer 3 capabilities, including OSPF, EIGRP, ISIS, RIP, and routed access
Advanced network monitoring using Full Flexible NetFlow
Cisc0 Software-Defined Access (SD-Access):
Simplified operations and deployment with policy-based automation from edge to cloud managed with Cisc0 Identity Services Engine
(ISE)
Product Description
|
Switch Model
|
The Gigabit Ethernet port
|
Uplink link interface
|
Uplink configuration
|
Default primary AC
power supply |
|
C9200-24T
|
24
|
24 ports data
|
Modular uplink options
|
PWR-C6-125WAC
|
|
C9200-24P
|
24
|
24 ports full PoE+
|
Modular uplink options
|
PWR-C6-600WAC
|
|
C9200-48T
|
48
|
48 ports data
|
Modular uplink options
|
PWR-C6-1KWAC
|
|
C9200-48P
|
48
|
48 ports full PoE+
|
Modular uplink options
|
PWR-C6-1KWAC
|
|
C9200L-24T-4G
|
24
|
24 ports data
|
4x 1G fixed uplinks
|
PWR-C5-125WAC
|
|
C9200L-24P-4G
|
24
|
24 ports full PoE+
|
4x 1G fixed uplinks
|
PWR-C5-600WAC
|
|
C9200L-48T-4G
|
48
|
48 ports data
|
4x 1G fixed uplinks
|
PWR-C5-125WAC
|
|
C9200L-48P-4G
|
48
|
48 ports full PoE+
|
4x 1G fixed uplinks
|
PWR-C5-1KWAC
|
|
C9200L-24T-4X
|
24
|
24 ports data
|
4x 1/10G fixed uplinks
|
PWR-C5-125WAC
|
|
C9200L-24P-4X
|
24
|
24 ports full PoE+
|
4x 1/10G fixed uplinks
|
PWR-C5-600WAC
|
|
C9200L-48T-4X
|
48
|
48 ports data
|
4x 1/10G fixed uplinks
|
PWR-C5-125WAC
|
|
C9200L-48P-4X
|
48
|
48 ports full PoE+
|
4x 1/10G fixed uplinks
|
PWR-C5-1KWAC
|
