Quick Details
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Triumph
-
Model Number:
-
UL2464
-
Temperature range:
-
-40℃~+80℃
-
Nominal voltage:
-
300V
-
Testing voltage:
-
1500V
-
Flammability rating:
-
VW-1
-
Jacket:
-
PVC Jacket
-
Conductor:
-
Bare Copper
-
Feature:
-
High flexible
-
Insulation:
-
color-coaded PVC.
-
Name:
-
UL2464
-
Core:
-
2 TO 10 CORE
Quick Details
-
Application:
-
Heating
-
Conductor Material:
-
soild or stranded, thinned copper
-
Conductor Type:
-
Stranded
-
Insulation Material:
-
PVC
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Triumph
-
Model Number:
-
UL2464
-
Temperature range:
-
-40℃~+80℃
-
Nominal voltage:
-
300V
-
Testing voltage:
-
1500V
-
Flammability rating:
-
VW-1
-
Jacket:
-
PVC Jacket
-
Conductor:
-
Bare Copper
-
Feature:
-
High flexible
-
Insulation:
-
color-coaded PVC.
-
Name:
-
UL2464
-
Core:
-
2 TO 10 CORE
Product Descriptio n
|
Product name |
UL2464 PVC insulated wire cable |
|
Cable length per roll |
200 /roll |
|
Conductor material |
Tinned copper, bare copper |
|
Insulation material |
PVC |
|
Color |
red-black-yellow-green-blue-white-orange-gray-brown-pink-yellow and green |
|
Temperature range |
80 ℃ |
|
Rated voltage |
300 V |
|
OEM |
Acceptable |
|
Features |
Must pass UL VW-1 and Ft1 vertical flame retardant tests, with uniform insulation thickness |
|
Uses |
Lead out connecting wires for household appliances, lighting fixtures, electronic equipment, temperature sensors, etc. |
|
Advantage |
Inventory spot, one roll up purchase |
|
Sample |
Free sample, customer pays freight |
Product S pecification
|
Conductor |
Insulator |
Packing |
|||
|
AWG |
CORE |
Conductor construction NO.Xmm |
DEGREE |
Over Diameter |
M/roll |
|
28 |
2C |
7/0.127TS |
80 ℃ |
3.4 |
200 |
|
3C |
7/0.127TS |
80 ℃ |
3.5 |
200 |
|
|
26 |
2C |
7/0.16TS |
80 ℃ |
3.6 |
200 |
|
3C |
7/0.16TS |
80 ℃ |
3.8 |
200 |
|
|
24 |
2C |
11/0.16TS |
80 ℃ |
3.8 |
200 |
|
3C |
11/0.16TS |
80 ℃ |
4.0 |
200 |
|
|
22 |
2C |
17/0.16TS |
80 ℃ |
4.2 |
200 |
|
3C |
17/0.16TS |
80 ℃ |
4.4 |
200 |
|
|
20 |
2C |
21/0.178TS |
80 ℃ |
4.6 |
200 |
|
3C |
21/0.178TS |
80 ℃ |
4.8 |
200 |
|
|
18 |
2C |
34/0.178TS |
80 ℃ |
5.2 |
200 |
|
3C |
34/0.178TS |
80 ℃ |
5.5 |
200 |
|
|
16 |
2C |
26/0.254TS |
80 ℃ |
6.3 |
200 |
|
3C |
26/0.254TS |
80 ℃ |
6.7 |
200 |
|
