Quick Details
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Bingshan
-
Voltage:
-
380V±5%/440V±5%
-
Power:
-
all available
-
Dimension(L*W*H):
-
customized size
-
Weight:
-
2000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Panel type:
-
polyurethane sandwich panels for prefabricated cold storage room
-
Product Type:
-
Cold Storage (Cold Room)
-
Compressor:
-
Bitzer, Bingshan
-
Functions:
-
fresh-keeping, frozen food storage, quick-freezing
-
capacity:
-
45M3
-
Door:
-
Sliding door or hinged door
Quick Details
-
Temperature:
-
-15~+20'C
-
Panel Thickness:
-
120mm
-
Cooling Capacity:
-
50000 ton
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
Bingshan
-
Voltage:
-
380V±5%/440V±5%
-
Power:
-
all available
-
Dimension(L*W*H):
-
customized size
-
Weight:
-
2000 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Panel type:
-
polyurethane sandwich panels for prefabricated cold storage room
-
Product Type:
-
Cold Storage (Cold Room)
-
Compressor:
-
Bitzer, Bingshan
-
Functions:
-
fresh-keeping, frozen food storage, quick-freezing
-
capacity:
-
45M3
-
Door:
-
Sliding door or hinged door
Product Description
Cold storage room features:
1. Temperature Range: - 20°C ~ + 10°C
2. Room Size: For 40GP and 20GP
3. Functions: Agricultural products, such as fruits and vegetable;
Components:
1 . Compressor: Bingshan, Bitzer, Panosonic, etc.
2. Refrigeration: R22, R717, R134A, etc.
3. Valve: Danfoss, etc.
4. Condenser: BAC evaporative condenser, Cooling tower, etc.
5. Evaporator: Bingshan air cooler, etc.
6. Panel: Palyurethane insulation panel, etc.
7. Control System: Bingshan Guardian, and etc.
Product Overviews
Volume Classification Table
|
Class |
Small |
Middle |
Large |
|
Volume Range |
<500m 3 |
500~10000m 3 |
>10000m 3 |
Store Body Heat Transfer Efficient Table
|
Store Temp. Class |
High |
Middle |
Low |
Freezing |
|
|
Heat Transfer Efficient W/m2.0°C |
Cold & Chilling |
≤0.48 |
≤0.38 |
≤0.26 |
≤0.23 |
|
CA |
≤0.51 |
≤0.40 |
≤0.38 |
~ |
|
Store Temp. Classification Table
|
Store Temp. Class |
High °C |
Middle °C |
Low °C |
Freezing °C |
|
|
Store Temp. Range |
Cold & Chilling |
-2~12 |
-10~-2 |
-20~-10 |
-30~-20 |
|
CA |
8~15 |
0~8 |
-2~0 |
|
|
Store Temp. Asymmetry Table
|
Single Unit Volume: m 3 |
≤500 |
>500 |
|
Store Temp. Asymmetry Table: 0°C |
≤4.0 |
≤6.0 |
Empty Store Temp. Descending Time Table
|
Single Unit Volume: m 3 |
Temp. Descending Time (h) |
||||
|
Low-temp. |
Middle-temp. |
Low-temp. |
Freezing |
||
|
Cold & Chilling |
≤100 |
≤1.0 |
≤1.5 |
≤2.5 |
≤3.5 |
|
101~1000 |
≤3.0 |
≤3.5 |
≤4.5 |
≤5.0 |
|
|
>1000 |
≤4.0 |
≤4.5 |
≤5.5 |
~ |
|
|
CA |
500~1000 |
≤5.0 |
|||
|
|
≤5.0 |
≤5.5 |
≤6.0 |
||
Trade Shows
Every year we attend about ten exhibitions, such as CARTON FAIR, WOFEX, etc.
Our Services
Engineer available to service overland
Packaging & Shipping
Export worthy packing
