Quick Details
-
Model Number:
-
CZ-40
-
Suitable wire:
-
core wire, electrical wire extruder
-
Extrusion material:
-
FEP, ETFE, PFA
-
Extruding conductor norm:
-
0.8mm~2.5mm (covered thickness 0.15-0.3 mm)
-
Suitable wire diameter:
-
1.2mm~3.0mm
-
Extrusion capacity:
-
20kg/hr
-
Max line speed:
-
200m/min
-
Central height:
-
1020mm
-
Voltage:
-
3phase 380V 50HZ
Quick Details
-
Use:
-
COATING
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Chuangzhan
-
Model Number:
-
CZ-40
-
Suitable wire:
-
core wire, electrical wire extruder
-
Extrusion material:
-
FEP, ETFE, PFA
-
Extruding conductor norm:
-
0.8mm~2.5mm (covered thickness 0.15-0.3 mm)
-
Suitable wire diameter:
-
1.2mm~3.0mm
-
Extrusion capacity:
-
20kg/hr
-
Max line speed:
-
200m/min
-
Central height:
-
1020mm
-
Voltage:
-
3phase 380V 50HZ
Product Description
| Model | CZ-50mm | CZ-60mm | CZ-65mm | CZ-70mm | CZ-80mm | CZ- 9 0mm | CZ- 10 0mm |
| Screw diameter | 50mm | 60mm | 65mm | 70mm | 80mm | 90mm | 100mm |
| Extrusion output | 70kg/hr | 100kg/hr | 120kg/hr | 150kg/hr | 200kg/hr | 250kg/hr | 300kg/hr |
| Wire diameter | 0.6-4.0mm | 0.8-8mm | 0.8-10mm | 1.5-12mm | 2-20mm | 3-25mm | 6-40mm |
| Max. Line speed | 500m/min | 450m/min | 400m/min | 350m/min | 200m/min | 150m/min | 80m/min |
| Capstan powder | 3HP | 4HP | 5HP | 5HP | 7.5HP | 7.5HP | 7.5HP |
