- Product Details
- {{item.text}}
Quick Details
-
Application:
-
Exterior
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZD
-
Model Number:
-
ZD-01-06
-
Name:
-
Adjustable Glass Spigot For Frameless Glass Railing Pool Fencing
-
Materail:
-
2205, 316, 316L, 304
-
Size:
-
6,8.5,9.5,10inch
-
Finish:
-
Satin, mirror , matt black, golden
-
Certificate:
-
ISO9001, ce, tuv
-
Glass:
-
12-20mm Tempered Glass/laminated Glass
-
Color:
-
Requirement
-
Installation:
-
Easy Diy Install
-
Item:
-
GS Glass Fencing
Quick Details
-
Warranty:
-
Lifetime
-
After-sale Service:
-
Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, NONE
-
Application:
-
Exterior
-
Design Style:
-
Modern
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZD
-
Model Number:
-
ZD-01-06
-
Name:
-
Adjustable Glass Spigot For Frameless Glass Railing Pool Fencing
-
Materail:
-
2205, 316, 316L, 304
-
Size:
-
6,8.5,9.5,10inch
-
Finish:
-
Satin, mirror , matt black, golden
-
Certificate:
-
ISO9001, ce, tuv
-
Glass:
-
12-20mm Tempered Glass/laminated Glass
-
Color:
-
Requirement
-
Installation:
-
Easy Diy Install
-
Item:
-
GS Glass Fencing
Product Details
|
Hot Sales 2205 Stainless Steel 6" 8.5" 9.5" 10" Adjustable Glass Spigot For Glass Railing Pool Fencing
|
|
|
|
|
||||
|
Material
|
Duplex stainless steel 2205/316L/316/304
|
|
|
|
||||
|
Size
|
6", 8.5", 9.5", 10"
Different height for different glass panels
|
|
|
|
||||
|
Glass Thickness
|
10-20mm glass
|
|
|
|
||||
|
Finish
|
Brushed Nickel , Mirror , Matt Black , Matt White , Golden
Non-conductive
Non-fading
Fire proof
No peeling off
10 years warranty time
|
|
|
|
||||
|
Function
|
1. Level adjustable
2. Glass tilt adjustable
3. Glass height adjustable
|
|
|
|
||||
|
Install
|
EASY DIY , no need hole on glass
|
|
|
|
||||
|
MOQ
|
1pcs
|
|
|
|
||||
|
Stock
|
5000pcs
|
|
|
|
||||
|
Delivery time
|
3-5days can be received by air
|
|
|
|
||||
|
Test
|
Loading test
Salt spray test
|
|
|
|
||||
|
Payment
|
T/T, Paypal, Credit card, Master Card
|
|
|
|
||||
Click the video to get different functions
Drawing - 6 styles for you choice
ZD-01-06 ,6" Height ,special design with patented
Two adjustments , level and glass tilt adjustable
ZD-01-06A , 6" Height, regular style,level adjustable
ZD-01-06B- 6" Height ,special design with patented
Two adjustments , level and glass height adjustable
Two adjustments , level and glass height adjustable
ZD-01-06C 8.5" with big opening to hold Max glass thickness 19mm
ZD-01-06D 10"
with big opening to hold Max glass thickness 19mm
ZD-01-06E 9.5" need one hole on glass
Mass Producion
Packing Details
6pcs/carton , 60cartons/pallet
Feedback
Test
|
Materil Test
|
stainless steel 304,316.316L
|
Duplex stainless steel 2205
|
Carbon /Alloy steel
|
||
|
Stress Test
|
4.5KN
|
6.5KN
|
7.5KN
|
||
|
Hard test
|
HRA
|
HRB
|
HRC
|
||
|
Strength Test
|
800Mpa
|
825Mpa
|
815Mpa
|
||
|
Glass
|
10,12mm
|
14,16mm
|
18,20mm
|
||
|
Glass Size
|
1*1.5m
|
1.5*1.8m
|
0.8*1.2m
|
||
|
Quantity
|
2,3pcs glass spigots for each glass
|
|
|
||
|
Material
|
C
|
Si
|
Mn
|
P
|
S
|
Cr
|
Ni
|
Mo
|
N
|
|
2205
|
0.02
|
0.511
|
1.307
|
0.023
|
0.018
|
22.512
|
5.508
|
3.145
|
0.15
|
|
316L
|
0.048
|
0.764
|
1.38
|
0.002
|
0.005
|
17.83
|
12.89
|
2.5
|
|
|
316
|
0.041
|
0.72
|
1.42
|
0.023
|
0.023
|
17.58
|
10.39
|
2.5
|
|
Our Factory
|
Factory
|
More Than 300 People
|
About 2000 SQM
|
80-100 Tons Mnothly
|
||
|
Certiticate
|
ISO9001:2008
|
CE
|
TUV
|
||
|
Patent
|
Designing
|
Utlity Model
|
Structure
|
||
|
Honor
|
Country Precision Casting
|
International Hardware
|
Designing
|
||
|
Payment
|
T/T , VISA ,Master Card ,Western Union ,Paypal ,L/C
|
|
|
||
|
Shipping
|
Air Express (3-5days)
|
Sea (20days)
|
Regular Air (5-7days)
|
||
|
Port
|
Qingdao ,Tianjin ,Shanghai ,Ningbo ,Guangzhou ,Dalian ,Shenzhen
|
|
|
||
