Quick Details
-
Brand Name:
-
MYAMI
-
Model Number:
-
MY-K20005E
-
Output Current:
-
5A
-
Product Name:
-
Laboratory power supply
-
Application:
-
DC System/Laboratory/Charge Battery/Motor Fields/Lab
-
Warranty:
-
1 Year
-
Display Type:
-
LED Digital Individually Displayed
-
Dimension:
-
330(D)250(W)155(H)mm
-
Weight:
-
5.5kg
-
Protections:
-
OPP OVP OTP OCP
-
Name:
-
Lab Bench Power
-
Type:
-
Constant Voltage
Quick Details
-
Input Voltage:
-
AC110V/220V±10%,50/60Hz
-
Output Voltage:
-
0-200V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MYAMI
-
Model Number:
-
MY-K20005E
-
Output Current:
-
5A
-
Product Name:
-
Laboratory power supply
-
Application:
-
DC System/Laboratory/Charge Battery/Motor Fields/Lab
-
Warranty:
-
1 Year
-
Display Type:
-
LED Digital Individually Displayed
-
Dimension:
-
330(D)250(W)155(H)mm
-
Weight:
-
5.5kg
-
Protections:
-
OPP OVP OTP OCP
-
Name:
-
Lab Bench Power
-
Type:
-
Constant Voltage
MYAMI MY-K20005 240V AC 200V 300V 400V 500V 600V 800V 1000V 5A Bench Top Lab DC power supply for Motor Testing RD
0-200V/0-5A variable/1000W
4LED digital
4LED digital
Application:
(1) Aerospace Testing
(1) Aerospace Testing
(2) Photovoltaic and energy storage system
(3) New energy vehicle
(4) Data center
(5) Industrial motor
(6) Power semiconductor module
(7) Automated test system (ATE)
(8) Lithium fuel cell
(9) Aging of electronic equipment
(10) Precision electroplating, splashing and surface treatment
(3) New energy vehicle
(4) Data center
(5) Industrial motor
(6) Power semiconductor module
(7) Automated test system (ATE)
(8) Lithium fuel cell
(9) Aging of electronic equipment
(10) Precision electroplating, splashing and surface treatment
Feature:
(1) Voltage and current can be preset;
(2) Voltage, current, power, equivalent resistance 4 Windows 4 high precision display at the same time;
(3) over voltage, over current, over power, over temperature, cornet 5 double protection;
(4) ON/OFF output on-off switch;
(5) 2 high quality coded switches, control voltage and current and thickness adjustment;
(6) SENSE compensation interface is optional at the back;
(7) It is equipped with communication serial port RS232 at the back, and the upper computer software can read and control the output on/off, voltage value and current value;
(2) Voltage, current, power, equivalent resistance 4 Windows 4 high precision display at the same time;
(3) over voltage, over current, over power, over temperature, cornet 5 double protection;
(4) ON/OFF output on-off switch;
(5) 2 high quality coded switches, control voltage and current and thickness adjustment;
(6) SENSE compensation interface is optional at the back;
(7) It is equipped with communication serial port RS232 at the back, and the upper computer software can read and control the output on/off, voltage value and current value;
Specification
|
Rated DC output (0℃~ 40℃)
|
|
|
|
Voltage
|
0-200V
|
|
|
Current
|
0-5A
|
|
|
Voltage stability
|
≤±(0.2%+0.05V)
|
|
|
Current stability
|
≤±(0.5%+0.05A)
|
|
|
Load stability
|
≤0.5%
|
|
|
Ripple & noise
|
≤1%
|
|
|
Display resolution
|
|
|
|
Voltage resolution
|
10mV
|
|
|
Current resolution
|
10mA
|
|
|
Power resolution
|
1mW
|
|
|
Load resistance
|
1mR
|
|
|
Operating environment
|
|
|
|
Elevation
|
≤2000m
|
|
|
Relative humidity
|
＜80%
|
|
|
Environment temperature
|
5℃~ 40℃
|
|
|
Storage environment
|
|
|
|
Environment temperature
|
-20~ 80℃
|
|
|
Relative humidity
|
≤80%
|
|
|
Power input
|
|
|
|
Input
|
AC220V±10%,50/60Hz
|
|
|
Size
|
|
|
|
Fuselage size
|
330(D)×250(W)×155(H)mm
|
|
|
Package size
|
430(D)×330(W)×250(H)mm
|
|
|
Weight
|
6.5Kg
|
|
|
Model
|
Voltage
|
Current
|
Display
|
Accuracy
|
|
MY-K1560E
|
0-15V
|
0-60A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K15100E
|
0-15V
|
0-100A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K2050E
|
0-20V
|
0-50A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K3020E
|
0-30V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K3030E
|
0-30V
|
0-30A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K3050E
|
0-30V
|
0-50A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K3060E
|
0-30V
|
0-60A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K3080E
|
0-30V
|
0-80A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30100E
|
0-30V
|
0-100A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30150E
|
0-30V
|
0-150A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30200E
|
0-30V
|
0-200A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K5020E
|
0-50V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K5030E
|
0-50V
|
0-30A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K5050E
|
0-50V
|
0-50A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K5060E
|
0-50V
|
0-60A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K6010E
|
0-60V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K6015E
|
0-60V
|
0-15A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K6020E
|
0-60V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K6030E
|
0-60V
|
0-30A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K6050E
|
0-60V
|
0-50A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K6060E
|
0-60V
|
0-60A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K8030E
|
0-80V
|
0-30A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K10005E
|
0-100V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K10010E
|
0-100V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K10020E
|
0-100V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K10030E
|
0-100V
|
0-30A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K12010E
|
0-120V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K12020E
|
0-120V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K12030E
|
0-120V
|
0-30A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K15005E
|
0-150V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K15010E
|
0-150V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K20002E
|
0-200V
|
0-2A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K20003E
|
0-200V
|
0-3A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K20005E
|
0-200V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K22010E
|
0-220V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K22020E
|
0-220V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30002E
|
0-300V
|
0-2A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30003E
|
0-300V
|
0-3A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30005E
|
0-300V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30010E
|
0-300V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K30020E
|
0-300V
|
0-20A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K40002E
|
0-400V
|
0-2A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K40003E
|
0-400V
|
0-3A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K40005E
|
0-400V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K40010E
|
0-400V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K50002E
|
0-500V
|
0-2A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K50003E
|
0-500V
|
0-3A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K50005E
|
0-500V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K50010E
|
0-500V
|
0-10A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K60002E
|
0-600V
|
0-2A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K60003E
|
0-600V
|
0-3A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K60005E
|
0-600V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K80001E
|
0-800V
|
0-1A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K80002E
|
0-800V
|
0-2A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K80003E
|
0-800V
|
0-3A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K80005E
|
0-800V
|
0-5A
|
4 LED
|
≤±(0.2%+0.05V)
|
|
MY-K80006E
|
0-800V
|
0-6A
|
4 LED
|
≤±(0.2%+0.05V)
|
