Quick Details
-
Power:
-
74KW
-
Dimension(L*W*H):
-
12900mm*2100m*4750mm
-
Weight:
-
150000 kg
-
mini concrete batching plant:
-
concrete batching plant
-
mobile concrete plant:
-
mobile concrete mix plant
-
portable concrete batch plant:
-
concrete mixing plant in china
Quick Details
-
Machine Type:
-
Production line
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HENGYOU
-
Power:
-
74KW
-
Dimension(L*W*H):
-
12900mm*2100m*4750mm
-
Weight:
-
150000 kg
-
mini concrete batching plant:
-
concrete batching plant
-
mobile concrete plant:
-
mobile concrete mix plant
-
portable concrete batch plant:
-
concrete mixing plant in china
Products Description
Concrete Batching Plant
Higher capacity, better configuration, Suitable for high quality concrete. It is mainly used in commercial concrete for sale and projects with high capacity requirements.
PRODUCT DETAILS
|
Model
|
YHZS-25
|
YHZS-35
|
YHZS-60
|
YHZS-100
|
|
Production capacity (m3/h)
|
20-25m³
|
30-35m³
|
55-60m³
|
95-100m³
|
|
Concrete mixer
|
JZM500
|
JZM750
|
JZM1500
|
JZM2000
|
|
Aggregate feeding mode
|
Belt conveyor
|
Belt conveyor
|
Belt conveyor
|
Belt conveyor
|
|
Aggregate size(mm)
|
80/60
|
80/60
|
80/60
|
80/60
|
|
Discharging height(m)
|
1.5
|
1.5
|
1.5
|
1.5
|
|
Aggregate weighing accuracy (%)
|
±2
|
±2
|
±2
|
±2
|
|
Cement weighing accuracy (%)
|
±1
|
±1
|
±1
|
±1
|
|
Water weighing accuracy (%)
|
±1
|
±1
|
±1
|
±1
|
|
Additive weighing accuracy (%)
|
±1
|
±1
|
±1
|
±1
|
|
Control system
|
control panel
|
control panel
|
control panel
|
control panel
|
|
Total power (kw)
|
42
|
46
|
67
|
77.5
|
|
Total weight(t)
|
12
|
13
|
14.5
|
26
|
Construction Scene
Details Images
Self-falling concr ete mixer
Stir evenly, no restrictions on aggregates
Forced double horizontal shaft mixer
The mixing speed is fast and more uniform, and the material has size restrictions.
Discharging speed
The pneumatic discharge has an opening adjustment device to adjust the discharge speed of different materials.
Powder conveyor
Versatile, reliable and economical mechanical conveyor for conveying various bulk powders
Bolted type cement silo
It takes up little space and can be quickly assembled and used for transitions.
Traction system
The number of tires can be customized, and the concrete mixing plant can be quickly transferred
