Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
HUATENG
-
Dimension(L*W*H):
-
150*100*120
-
Weight:
-
600
-
Rated power/speed:
-
48-74/1500-2500(KW/RPM)
-
Marketing Type:
-
New Product 2023
-
Engine Model:
-
F6L912 Engine
-
MOQ:
-
1set
-
Delivery:
-
7-15 Work Days
Quick Details
-
Displacement:
-
5.655L
-
Emission Standard:
-
Euro 2
-
Power:
-
48-74kw
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
HUATENG
-
Dimension(L*W*H):
-
150*100*120
-
Weight:
-
600
-
Rated power/speed:
-
48-74/1500-2500(KW/RPM)
-
Marketing Type:
-
New Product 2023
-
Engine Model:
-
F6L912 Engine
-
MOQ:
-
1set
-
Delivery:
-
7-15 Work Days
|
Model
|
Bore/
Stroke (mm)
|
Displacement（L）
|
Power/Rotating Speed (kw/rpm)
|
|
|
|
|||
|
F2L912
|
100/120
|
1.88
|
14/1500
|
17/1800
|
20/2300
|
|
|||
|
F3L912
|
100/120
|
2.828
|
24/1500
|
29/1800
|
36/2300
|
38/2500
|
|||
|
F4L912
|
100/120
|
3.77
|
32/1500
|
38/1800
|
46/2300
|
51/2500
|
|||
|
F6L912
|
100/120
|
5.655
|
48/1500
|
60/1800
|
74/2500
|
78/2500
|
|||
|
F3L912W
|
100/120
|
2.828
|
29/2150
|
31/2300
|
33/2500
|
|
|||
|
F4L912W
|
100/120
|
3.77
|
39/2150
|
42/2300
|
44/2500
|
|
|||
|
F6L912W
|
100/120
|
5.655
|
60/2150
|
63/2300
|
66/2500
|
|
|||
DIMENSIONS
|
Engine type
|
|
A
|
B
|
C
|
||||
|
F3L 912
|
mm
|
691
|
680
|
800
|
||||
|
F4L 912
|
mm
|
837
|
680
|
800
|
||||
|
F6L 912
|
mm
|
1094
|
680
|
838
|
||||
|
F3L 912w
|
mm
|
697
|
679
|
796
|
||||
|
F3L 912w
|
mm
|
807
|
679
|
796
|
||||
|
F3L 912w
|
mm
|
1084
|
679
|
806
|
||||
|
Depending on the scope of delivery, there are different motor dimensions and weights.
|
|
|
|
|
||||
|
All information is for information only and represents non-binding values. For further information, please contact the responsible sales outlet.
|
|
|
|
|
||||
|
STANDARD CONFIGURATION
|
|
OPTIONAL CONFIGURATION
|
|
||
|
1.
Oil filter
2.
Diesel filter
3.
Oil bath air cleaner with pre-cleaner and dust collector
4.
12V/24V starting motor
5.
12V/24V charged generator
6.
Diesel engine electrical shutdown device(only generator set)
7.
Automatic belt tension unit
8.
V-belt break alarm device
9.
Belt guard(only for generator set)
10.
4 Engine elastic supports
11.
SAE Flywheel and housing
12.
Oil temperature sensor and alarm switch (VDO analog signal)
13.
Oil pressure sensor and alarm switch (VDO analog signal)
14.
Diesel engine accelerator adjust device (only generator set)
15.
Mechanical adjusting speed device
16.
Diesel engine paint(gray)
|
|
1.
Gear driven hydraulic pump
2.
Belt driven air compressor
3.
Hydraulic oil radiator
4.
Starting aid for engine starting below minus 5℃ down to minus 20℃
5.
12V/24V Diesel engine electrical adjusting speed control device
6.
All kinds of meter of diesel engine
|
|
||
