Quick Details
-
Dimension(L*W*H):
-
Customer Request
-
Year:
-
2024
-
Power (kW):
-
5 kW
-
Weight (KG):
-
1600 KG
-
machine oil:
-
automatic pressure compensation and oil pump stop delay function
-
easy to operate:
-
manual, semi-automatic two modes
-
hydraulic cylinder:
-
reliable sealing and long service life
-
imported high-pressure oil pump:
-
low noise and low energy consumption
-
fuel tank:
-
more time-saving and human-friendly
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Chaoguangyue
-
Voltage:
-
Customer Request
-
Dimension(L*W*H):
-
Customer Request
-
Year:
-
2024
-
Power (kW):
-
5 kW
-
Weight (KG):
-
1600 KG
-
machine oil:
-
automatic pressure compensation and oil pump stop delay function
-
easy to operate:
-
manual, semi-automatic two modes
-
hydraulic cylinder:
-
reliable sealing and long service life
-
imported high-pressure oil pump:
-
low noise and low energy consumption
-
fuel tank:
-
more time-saving and human-friendly
Curing Press Hydraulic Tyre Curing Press to truck chain
Note: We can design the different size of machine according to the requests for products.
it is mainly in use of vulcanizing various kinds of rubber pattern products.
high quality best price
easy handing
fast delivery
design upon your request
As a professional manufacturer and exporter of rubber machine of China, we can supply quality vulcanizing rubber machine, open mixing mill, rubber kneader to you with competitive price and give guarantee to the quality. we also can custom-made non-standard machine according to your requirement.
Technical Parameter:
|
VERSION |
XLB350X350X2 |
XLB350X400X2 |
XLB500X500X2 |
XLB600X600X2/4 |
XLB750X850X2 |
|
Mould closing force(MN) |
0.25 |
0.5 |
0.8 |
1.0 |
1.6 |
|
Daylight(mm) |
125 |
125 |
125 |
125 |
125 |
|
opening |
2 |
2 |
2 |
2/4 |
2 |
|
Platen unit area pressure(Mpa) |
2.04 |
3.13 |
2.52 |
2.78 |
2.51 |
|
Plunger stroke |
250 |
250 |
250 |
250 |
250 |
|
Heating way |
Electricity/steam |
Electricity/steam |
Electricity/steam |
Electricity/steam |
Electricity/steam |
|
Main motor power |
2.2 |
2.2 |
2.2 |
2.2 |
3 |
|
Size(length*width*height)mm |
1450x400x1350 |
1450x690x1440 |
1450x690x1818 |
1880x780x1660 |
2100x1010x1900 |
|
Weight(kg) |
1200 |
1500 |
1700 |
2500/3100 |
3560/4300 |
|
Structure form |
Strain rod |
Strain rod |
Strain rod |
Strain rod |
Strain rod/plate |
