Amerigo Hydraulic Scissor Alignment Car Lift Lifting Capacity 5000kg

Amerigo Hydraulic Scissor Alignment Car Lift Lifting Capacity 5000kg

FOB Reference Price: Get Latest Price

≥1 Sets

US $1100

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Shanghai, China

Brand Name:: Amerigo

Model Number:: Amg-YJ50CBL

Warranty:: 15 Months

Use:: Auto maintenance

Name:: Amerigo Hydraulic Scissor Alignment Car Lift Lifting Capacity 5000kg

Color:: Customer Request

Mode of drive:: Hydraulic drive

Function:: Alignment scissor lift

Platform legnth:: 4300mm

Power Supply:: 380V/2.2KW

Place of origin:: China

Capacity:: 5000kg

Usage:: 4S Shops

Quick Details

Lifting Capacity:: 5000kg

Lifting Height(mm):: 1880mm

Overall Width(mm):: 2130mm

Place of Origin:: Shanghai, China

Brand Name:: Amerigo

Model Number:: Amg-YJ50CBL

Warranty:: 15 Months

Use:: Auto maintenance

Name:: Amerigo Hydraulic Scissor Alignment Car Lift Lifting Capacity 5000kg

Color:: Customer Request

Mode of drive:: Hydraulic drive

Function:: Alignment scissor lift

Platform legnth:: 4300mm

Power Supply:: 380V/2.2KW

Place of origin:: China

Capacity:: 5000kg

Usage:: 4S Shops

Product Description

Amerigo Hydraulic Scissor Alignment Car Lift Lifting Capacity 5000kg

Double level scissor lift, 205mm above the ground at the lowest level

Adopt Italy technology to design

6 cylinders, double hydraulic balance system (main lift) and mechanical safety with automatic unlock are equipped

24V safety control circuit

Oil cylinder parts made by automatic high rotation speed CNC lathe ensure the excellent finish and concentricity

Japanese oil sealing elements,ltalian spherical valve, oil pipe explosion protective device, overload protection, international brand oil pipe

Components are made by laser cutting machine or other CNC equipment

Alloy solid steel X structure, good rust resietance and not easy to deformation

Shot blasting and high temperature baking powder coated surface finish

Second-level extensible platform

Wear-resisting bearings,polymer wear-resistance slider

Optional infra-red electronic leveling sensor,optional anti presser foot device

Technical parameters

Model	Capacity of Main Lift	Capacity of Sub-lift	Main Lift Lifting Height	Sub-lift Lifting Height	Main Lift Platforn Lenght
Amg-YJ50CBL	5000kg	50000kg	1880mm	500mm	4300mm
	Main Lift Platforn Width	Sub-lift Platform Heigh	Sub-lift Platform Width	Motor Power	Air Pressure
	625mm	1460-1760mm	565mm	380V/220V 2.2KW	0.4-0.6Mpa
