power inverter 3000w 120v 240v pure sine wave 12v to battery true sine wave 1000w 2000 3000 5000 watt generator 240v

power inverter 3000w 120v 240v pure sine wave 12v to battery true sine wave 1000w 2000 3000 5000 watt generator 240v

FOB Reference Price: Get Latest Price

≥1 Pieces

US $185

≥22 Pieces

US $145

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: LW series 1-6kw

Output Frequency:: 50/60Hz

Size:: (L*W*H)480*225*190mm

Weight:: 20kgs - 48kgs

Product name:: 1KW 2KW 3KW 4KW 5KW 6KW Pure Sine Wave Off Grid PowerInverter

Warranty:: 24 Months

Certificate:: CE , IEC ,ISO9001 , ETL, CE

Application:: TV ,computer, fan, airconditioner

Output waveform:: Pure Sine Wave

Peak power:: 3 times of rating power

Working modes:: AC/DC priority modes can be set

Protection:: overload , low battery , short circuit

LCD display:: set and show the inverter parameters

Current:: 35A/50A/70A/90A

Quick Details

Output Current:: Load

Place of Origin:: Guangdong, China

Brand Name:: Power star W7

Model Number:: LW series 1-6kw

Output Frequency:: 50/60Hz

Size:: (L*W*H)480*225*190mm

Weight:: 20kgs - 48kgs

Product name:: 1KW 2KW 3KW 4KW 5KW 6KW Pure Sine Wave Off Grid PowerInverter

Warranty:: 24 Months

Certificate:: CE , IEC ,ISO9001 , ETL, CE

Application:: TV ,computer, fan, airconditioner

Output waveform:: Pure Sine Wave

Peak power:: 3 times of rating power

Working modes:: AC/DC priority modes can be set

Protection:: overload , low battery , short circuit

LCD display:: set and show the inverter parameters

Current:: 35A/50A/70A/90A

Product Details

Split phase low frequency pure sine wave inverter charger 1-6KW compatible LifePO4 battery/Lead acid battery /GEL battery/car battery selectable current.

1. Split phase inverter 120/240V output ,Can work with inductive load such as air conditioner , motor door and so on.
2. 4-step progressive charging, 7 battery type selector.
3. Fast and powerful charger with 20A/35A/50A/70A/90A.
4. Accept generator’s energy output.
5. Automatically transfer between battery and line modes.
6. Microprocessor control guarantees high reliability.
7. Protection against: Over load, over temperature, over charging, low battery.

Installation Pictures from Customers

Specifications

Model			Power star Inverter
AC Input	Nominal Power	1000W 2000W 3000W 4000W 5000W 6000W
		Voltage	120VAC/230VAC
		Acceptable Voltage	93-138VAC /194-243VAC/164-243VAC(wide mode)
		Line low Transfer	85V±4%/184(154 wide mode±4% )
		Line low Return	95V±4%/194(164 wide mode±4% )
		Line high Transfer	135V±4%/253±4%
		Line high Return	127V±4%/243±4%
		Frequency	50Hz or 60Hz (auto sensing)
		Line low Transfer	47Hz for 50Hz, 57Hz for 60 Hz
		Line high Transfer	55Hz for 50Hz, 65Hz for 60 Hz
Out Input	Phase &waveform	Pure Sine Wave(bypass mode sync to input)
		Voltage	100/110/120/130VAC, 208/220/230/240VAC (bypass mode sync to input)
		Voltage Regulation	±10%rms(bypass mode sync to input)
		Frequency	50Hz±0.3Hz(bypass mode sync to input)
		Peak Power	3 times of rating power
		Short Circuit Protection	Yes, shutdown after 10ms
		Power Factor	0.9-1.0
DC Input	Battery Voltage	24V/48V
		Minimum Start Voltage	10V for 12V, 20V for 24V, 40V for 48V
		Low Battery Alarm	10.5V for 12V, 21V for 24V, 42V for 48V
		Low Battery Transfer	10V for 12V, 20V for 24V, 40V for 48V
		High Voltage Alarm	16V for 12V, 32V for 24V,64V for 48V
		Max Charging Current	20A/35A/70A/90A
		Over charge Voltage	15.7V for 12V,31.4V for 24V, 62.8V for 48V
Transfer Efficiency	Line Mode	>95%
		Battery Mode	>88%
		Power saver	Available when the load is less than 25 Watts
Indicators	Switch selector	Saving Mode is on/off when push the switch forwards/backwards , Keeping it horizontal is turning the inverter off.
		Audible Alarm	Sounding when the heatsink’s tem is over 105℃ and shutdown after 30 seconds.
		Protections	low battery/ over charging /over temp/over load
		Communications	RS-232/USB(custom-made)
Enviromental	Operating Environment	0-40℃,0-90%℃ RH(non-condensing)
		Audible Noise	<60dB
		Net Weight (KG)	40
		Dimension(LxWxH)	605×218×179mm

Certifications

Shipping&Packing

Shipping: company standard
Delivery: sea transaction, air parcel, international express service(FEDEX, DHL, TNT, UPS, Shunfeng Exprress, and so on).

FAQ

Q1.How is your product quality?

A: QC regularly check the quality . We have been working with large solar inverters company. Our products were damaged less than
3% over the past five years. Regarded as a high quality inverter supplier.

Q2.When the product have problem, how to solve it?

A:We have a professional after-sales team, in case of any problems, first contact us to help you solve,
we have a 24 months warranty.We will track product usage until you are satisfied.

Q3.Can you accept OEM, ODM service?
A:Yes, we accept OEM,ODM service.

Q4.What kind of certificate you have ?
A:Our company already achieve ISO, CCC, and for products, we have CE, ETL, Thayer, UL .

Q5. what's the payment term?
A: We accept TT,30% deposit and 70% balance against copy of B/L

Q6. How's the delivery time ?
A: Usually it will take about 5-7 workdays for production

Q7.What kind of material of transformer?
A:we have two types, one 100% copper and the other is copper with aluminum.It depends on your requirement. In fact,those two have
no difference if normal work well. Only except the long life. Copper is better and also higher price.

Q8: What's the different between inverter and solar inverter?
A: Inverter is only accept AC input, but solar inverter not only accept AC input
but also can connect with solar panel to accept PV input, it more save power.

Q9.Do you have unique advantages?

A:Five sales teams are responsible for different markets, with an average staff of 4 and a half years in the company.
R & D team ensure that each year for different markets launch 4 to 7 products listed.
