Quick Details
-
Voltage:
-
No
-
Dimension(L*W*H):
-
3000*1520*2200mm
-
Weight:
-
2400kg
-
Working Pressure:
-
14.5bar
-
Air capacity:
-
550CFM
-
Working pressure:
-
25Bar
-
Capacity:
-
33m3 /min (464cfm)
-
MOQ:
-
1 Set
-
Usage:
-
Drilling
-
Engine:
-
Cummins
-
Drive method:
-
Screw
-
Brand:
-
KAISHAN Brand
-
Key words:
-
Screw Compressor Air
-
Application:
-
Compressed Air
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Kaishan
-
Model Number:
-
KSCY550-14.5
-
Voltage:
-
No
-
Dimension(L*W*H):
-
3000*1520*2200mm
-
Weight:
-
2400kg
-
Working Pressure:
-
14.5bar
-
Air capacity:
-
550CFM
-
Working pressure:
-
25Bar
-
Capacity:
-
33m3 /min (464cfm)
-
MOQ:
-
1 Set
-
Usage:
-
Drilling
-
Engine:
-
Cummins
-
Drive method:
-
Screw
-
Brand:
-
KAISHAN Brand
-
Key words:
-
Screw Compressor Air
-
Application:
-
Compressed Air
Products Description
1.
Main engine
: patented large-diameter rotor design. The main engine is directly connected with the diesel engine through a highly elastic coupling, and there is no speed-increasing gear in the middle. The speed of the main engine is the same as that of the diesel engine, with higher efficiency, better reliability and longer service life.
2.
Diesel engine
: Cummins, Yuchai and other domestic and foreign famous diesel engines are selected, which meet the national II emission requirements, have strong power and low fuel consumption, and have a nationwide after-sales service system, so that users can get rapid and perfect service.
3. The gas volume control system is simple and reliable. According to the gas consumption, the intake air volume is automatically adjusted by 0~100%, and the throttle of the diesel engine is automatically adjusted to save diesel to the maximum extent.
4.Microcomputer intelligently monitors the operating parameters such as air compressor exhaust pressure, exhaust temperature, diesel engine speed, oil pressure, water temperature, oil tank level, etc., with automatic alarm and shutdown protection functions.
5,multistage air filter, suitable for dusty working environment; Multi-stage fuel filter, suitable for domestic oil quality status; Super large oil-water cooler, suitable for high temperature and plateau environment.
6, spacious maintenance door, the parts to be maintained are within reach, it is convenient and easy to maintain air filter, oil filter, fuel tank, battery and oil cooler, reducing downtime.
7. It is convenient to move, and it can still move flexibly under harsh terrain conditions. Each compressor is equipped with lifting rings for safe and convenient lifting and transportation.
Product Parameter
|
product model
|
Exhaust pressure ( Mpa)
|
Displacement (m3/min)
|
Matching engine power (KW)
|
Exhaust interface
|
Weight (kg)
|
Overall dimension (mm)
|
|
KSCY-220/8
|
0.8
|
6
|
55
|
G1 1/4×1，G3/4×1
|
1440
|
3000×1760×1820
|
|
KSCY-330/8
|
0.8
|
9.5
|
88
|
G1 1/4×1，G3/4×1
|
1550
|
3240×1760×1785
|
|
KSCY-360/13
|
1.3
|
10
|
118
|
G1 1/2×1，G3/4×1
|
1880
|
3300×1880×2100
|
|
KSCY-425/10
|
1
|
12
|
118
|
G1 1/2×1，G3/4×1
|
1880
|
3300×1880×2100
|
|
KSCY-400/14.5
|
1.45
|
11
|
118
|
G1 1/2×1，G3/4×1
|
1880
|
3300×1880×2100
|
|
KSCY-550/13
|
1.3
|
15
|
132
|
G1 1/2×1，G3/4×1
|
2400
|
3000×1520×2200
|
|
KSCY-550/13
|
1.3
|
15
|
140
|
G1 1/2×1，G3/4×1
|
2400
|
3000×1520×2200
|
|
KSCY-560/15
|
1.5
|
16
|
140
|
G1 1/2×1，G3/4×1
|
2400
|
3000×1600×2230
|
|
KSCY-580/17
|
1.7
|
17
|
194
|
G2×1，G3/4×1
|
3200
|
3200×1800×2450
|
|
KSCY-580/17
|
1.7
|
17
|
194
|
G2×1，G3/4×1
|
3200
|
3200×1800×2450
|
|
KSCY-680/14.5
|
1.45
|
19
|
194
|
G2×1，G3/4×1
|
3200
|
3200×1800×2450
|
|
KSCY-750/20
|
2
|
22
|
228
|
G2×1，G3/4×1
|
3900
|
3300×1800×2300
|
