Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
IFAN
-
Model Number:
-
Full
-
product name:
-
PEX Pipe Fitting
-
Color:
-
Red/Yellow/White/Blue/Customization
-
Size:
-
16-32mm
-
Application:
-
Water Pipe System
-
Raw Material:
-
Brass
-
Sample:
-
Free
-
Advantage:
-
Long Service Life
-
Packing:
-
IFAN standard packaging
-
Feature:
-
Easy assemble, Eco-friendly, Durable
Quick Details
-
Technics:
-
Forged
-
Shape:
-
Equal
-
Head Code:
-
Round
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
IFAN
-
Model Number:
-
Full
-
product name:
-
PEX Pipe Fitting
-
Color:
-
Red/Yellow/White/Blue/Customization
-
Size:
-
16-32mm
-
Application:
-
Water Pipe System
-
Raw Material:
-
Brass
-
Sample:
-
Free
-
Advantage:
-
Long Service Life
-
Packing:
-
IFAN standard packaging
-
Feature:
-
Easy assemble, Eco-friendly, Durable
Alibaba 16 Years--Product Specification
|
Name
|
PEX Press Fittings
|
|
Size
|
1/2''-1''
|
|
Material
|
Brass
|
|
Color
|
Silver
|
|
Package
|
IFAN opp bag + carton
|
|
Support
|
OEM & ODM
|
|
Application
|
Hot & cold water system and floor heating system
|
|
Sample
|
PEX Press Fittings
PEX Press Fittings is a kind of connecting piece that connects pipes with socket pipe fittings with special sealing rings, and uses special tools to press the pipe mouth to seal and fix it. It has anti-pull, anti-rotation, simple and convenient installation, and needs Small operating space, shock resistance, maintenance-free after installation and so on.
Advantage:
1. The connection is reliable and reliable. The compression-type pipe fittings have high connection strength and anti-vibration, which can make the connection part "dead" at one time, thus avoiding the possibility of "live connection".
2. The construction is convenient and fast. Avoid on-site welding and threading operations. On-site welding or threading of pipe fittings is laborious, with high water leakage rate, polluting the environment, and easily generating risks.
3. Maintenance-free and update-free, superior economic performance.
4. Suitable for embedded installation. The press-type pipe fittings meet the requirements of pre-embedded installation, which greatly reduces the possibility of water leakage in concealed environments.
Alibaba 16 Years--Product Size
|
PEX Pipe Size
|
|
|
|
|
||||
|
Overlap
|
Laser
|
Insulating
|
Gas
|
Stabi
|
||||
|
1216
1418
1620
2025
2026
2632
|
1216
1418
1620 2025 2026 2632 |
1216
1418
1620 2025 2026 2632 |
1216
1418
1620 2025 2026 2632 |
16.2 x 2.620 x2.9
25 x 3.7 32 x 4.7 40 x6.0 |
||||
|
PEXA
|
PEXB
|
PEXC
|
PERT
|
ASTM
|
||||
|
16x2.0
16x2.2
20x2.0
20x2.8
25x3.5
32x4.4
|
16x2.0
16x2.2
20x2.0
20x2.8
25x3.5
32x4.4
|
16x2.0
16x2.2
20x2.0 20x2.8 25x3.5 32x4.4 |
16x2.0
16x2.2
20x2.0 20x2.3 20x2.8 25x3.5 32x4.4 |
1/8"(6.35x1.19)
1/4"(9.52x1.57) 5/16(10.92x1.63)
3/8"(12.7x1.78) 1/2(15.88x1.78)
5/8"(19.05x2.12)
3/4"(22.22x2.47)
1"(28.58x3.18)
1-1/4"(34.92x3.88)
1-1/2"(41.28x4.59) 2''(53.98x6.0)
|
||||
|
Other
|
|
|
|
|||||
|
PEX Press Fittings Size
|
|
|
|
|
||||
|
Socket
|
S16×16
|
S20×20
|
S25×25
|
S32×32
|
||||
|
Reduce Socket
|
S16×20
|
S20x25
|
S32×20
|
S32×25
|
||||
|
Female Socket
|
S16×1/2''F
S18×1/2F
|
S20×1/2''F
S20×3/4"F
|
S25×3/4"F
S25×1"F
|
S32×1''F
|
||||
|
Male Socket
|
S16×1/2''F
S18×1/2F
|
S20×1/2''F
S20×3/4"F
|
S25×3/4"F
S25×1"F
|
S32×1''F
|
||||
|
Elbow
|
L16×16
L18×18
|
L20×20
|
L25×25
|
L32×32
|
||||
|
Reduce Elbow
|
L20×16
|
L25×20
|
L32×20
|
L32×25
|
||||
|
Female Elbow
|
L16×1/2"F
L18×1/2"F
|
L20×1/2"F
L20x3/4"F
|
L25x3/4"F
L25x1"F
|
L32x1"F
|
||||
|
Male Elbow
|
L16×1/2’‘M
L16×3/4’‘M
|
L20×1/2"F
L20x3/4"F
|
L25x3/4"F
L25x1"F
|
L32x1"F
|
||||
|
Seated Elbow
|
ZL16×1/2''F
|
ZL18×1/2''F
|
ZL20×1/2''F
|
|
||||
|
Double Elbow
|
16×1/2''
|
18×1/2''
|
|
|
||||
|
Tee
|
T16×16×16
T18×18×18
|
T20×20×20
|
T25×25×25
|
T32×32×32
|
||||
|
Reduce Tee
|
T16x20x16
T20x16x20
|
T25×16×25
T25×20×25
|
T32x16x32 T32x20x32 T32x25x32
|
|
||||
|
Female Tee
|
T16×1/2''F
T18×1/2''F
|
T20×1/2''F
T20×3/4"F
|
T25x3/4"F
T25×1"F
|
T32x1"F
|
||||
|
End Cap
|
S16
|
S20
|
S25
|
|
||||
|
Union
|
16×1/2''
18×1/2''
|
20×1/2''
20×3/4''
|
25×3/4''
|
32×1''
|
||||
|
Other
|
|
|
|
|||||
Alibaba 16 Years--Product Display & Connection Steps
01
Expand the diameter of the pipe with PEX round tools.
02
Nest the fitting into the pipe.
03
Use pliers to clamp the cover，finish the installation.
Alibaba 16 Years--Why Choose Us
Alibaba 16 Years--One-Stop Shopping With IFAN
Alibaba 16 Years--IFAN Factory & Customer Praise
Alibaba 16 Years--FAQ
Q: Are you a manufacture or trading company ?
A: Yes. we're professional manufacture in China,and have been in this field for more than 30 years.
Q: What payment terms do you support ?
A: TT,L/C, Western Union,Money Gram areavailable, and for TT we accept 30% deposit inadvance.70% balance against copy of B/L.
Q: How long is your delivery time ?
A: 15-30days after receiving deposit.
Q: lt is possible to get samples from your factory ?
A: Yes. free samples will be sent if needed, but thefreight can be negotiated or
chargeable, it will berefunded after confirmation of the orders.
