Electric 50kw Stirling Power Inverter Generator Stirling Engine Backup Diesel Power 4 Cylinder Marine Power Diesel Generators

Electric 50kw Stirling Power Inverter Generator Stirling Engine Backup Diesel Power 4 Cylinder Marine Power Diesel Generators

FOB Reference Price: Get Latest Price

≥1 Sets

US $2980

≥5 Sets

US $2950

≥12 Sets

US $2900

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Fujian, China

Brand Name:: JUSTPOWER

Model Number:: JPG60PS

Speed:: 1500RPM/1800RPM

Weight:: Dependent

Product Name:: Diesel Generator

ATS System:: Optional

Preheating system:: Optional

Control system:: Smart Controller

Fuel tank capacity:: 8 Hours Continue Running

Alternator type:: 100% Copper Wire Alternator

Cooling system:: Closed Water-cooling System

Keyword:: Generators Prices

Quick Details

Rated Voltage:: 110V/220V/230V/380V/400V/415V/440V

Rated Current:: Dependent

Frequency:: 50 Hz/ 60 Hz

Place of Origin:: Fujian, China

Brand Name:: JUSTPOWER

Model Number:: JPG60PS

Speed:: 1500RPM/1800RPM

Weight:: Dependent

Product Name:: Diesel Generator

ATS System:: Optional

Preheating system:: Optional

Control system:: Smart Controller

Fuel tank capacity:: 8 Hours Continue Running

Alternator type:: 100% Copper Wire Alternator

Cooling system:: Closed Water-cooling System

Keyword:: Generators Prices

Products Description

1	Brand new water-cooled diesel engine with 50ºC tropical radiator.
2	Brand new brushless alternator, 2 years warranty.
3	Deepsea/ComAp/Smartgen/Justpower digital smart controller.
4	Maintenance-free battery with battery cable, battery terminal caps and battery isolator switch.
5	Oil, coolant, fuel and water drain on the base frame. So make it easier to clean your genset.
6	Hight quality anti-vibration pads between engine/alternator and base frame.
7	0%, 25%, 50%, 75%,100%,110% loading test for each generator before shipment.
8	Genset with 8-10 hours basis fuel tank.
9	General manuals in English that illustrates the quality and added values of manufacturing.
10	Basic spare parts and tools are provided for all models.
11	Using 100% free-resistant sound attenuation material, with good adhesive strength and ensures tha the sound attenuation materials do not fall off over time.
12	Manufacured strictly according to ISO9001-2008, GB/T19001-2008 internatioal quality management system.
Optional
1	50Hz (380/220V, 400/230V, 415V/240V, 440V etc) Or 60Hz (110/220V, 115/230V,127/220V, 220/440V, etc )
2	Single phase or Three phase
3	ATS(Automatic Transfer Switch)
4	Water/oil/air pre-heater
5	Genset in 20FT/40HQ container design
6	Other requirements

JUSTPOWER Silent Canopies

• JUSTPOWER manufactures a complete line of genset canopies. During the process, we try our best to ensure the most suitable engineering design, the highest level of durability, and best performance in noise control and weather resistance of each genset.

• All-steel enclosures ensure long life span and reliable protection over generator equipments. Resigned with feet for easy lifting.

• By spray coating process, paint particles evenly cover each part of the metal surface for lasting protection of canopy and base fuel tank against the elements.

• Design with 180 degree swing doors to ensure full access to insider equipments for easy maintainence. Also provide built-in box and trays for placing tools and batteries.

• Industrial steel basis built and designed to withstand high-torque transient conditions and eliminate vibrations. With vibration dampers between engine & alternator and chassis. Basis-integrated fuel tank ensure long-time continuous operation of genset.

Alternator - Generator

• Two full load testing processes to ensure product quality

• Reliable performance • 100% copper, 100% power

• H Class insulation • Stable voltage output • Synchronous type

• With reliable performance stable voltage output and long lifespan.

• High quality materials, like 800 silicon, H class insulation and 100% pure copper wire.

• AVR Automatic Voltage Regulated for clean safe power for all your sensitive electronics .

Engine

• Strong output • Good performance

• Good fuel utilization • Long lifespan • Easy avalibility of spare parts

• Heavy-duty industrial diesel engine

• We are OEM partner for Perkins, Cummins, Deutz, WeiChai , Isuzu, FAW , YTO & SIDA .

• JUSTPOWER searches and tests various industrial heavy-duty engine to find engine with maximum performance, better fuel utilization and longer lifespan to power our genset.

Control system

• Automatic controllers are available. • Monitor & control all key parameters. • User-friendly operating interface

• Easy operation for start & stop • Genset protection • ATS & remote control are optional

• Safety warning and shut-down levels

• Easy operation compact design

• One-click starting, easy operation.

wiring

• Well-arranged wire connection

• Each line has an independent serial number. when you need to do the maintenance, just follow our wiring diagram.

• Wiring Use anti-flaming and heat-resistant silicon rubber wires for safe operation.

Power Range

JUSTPOWER PERKINS SERIES DIESEL GENERATORS 9KVA-2200KVA 50Hz/1500RPM

GENSET MODEL

POWER KW/KVA

Engine

Alternator

Fuel Capacity

(L)

Displacement

(L)

Dimension

(mm)

JPG9PS

7.2/9

403D-11G

PI044E

1.1

1730X850X1150

JPG13PS

10/12.5

403A-15G1

PI044F

1.496

1730X850X1150

JPG15PS

12/15

403A-15G2

PI044G

1.496

1730X850X1150

JPG20PS

16/20

404D-22G

PI144D

2.2

1950X900X1150

JPG25PS

20/25

404D-22TG

PI144E

2.2

1950X900X1150

JPG30PS

24/30

1103A-33G

PI144G

3.3

2300X1000X1400

JPG45PS

36/45

1103A-33TG1

UCI224D

3.3

2300X1000X1400

JPG60PS

48/60

1103A-33TG2

UCI224E

100

3.3

2300X1000X1400

JPG80PS

64/80

1104A-44TG2

UCI224G

130

4.4

2600X1080X1450

JPG100PS

80/100

1104C-44TAG2

UCI274C

160

4.4

2600X1080X1450

JPG135PS

108/135

1106A-70TG1

UCI274E

220

7.01

2850X1080X1650

JPG150PS

120/150

1106A-70TAG2

UCI274F

240

7.01

3200X1130X1750

JPG180PS

144/180

1106A-70TAG3

UCI274G

290

7.01

3400X1250X1750

JPG200PS

160/200

1106A-70TAG4

UCI274H

320

7.01

3800X1350X1950

JPG230PS

180/230

1206A-E70TTAG2

UCDI274J

360

7.01

3800X1350X1950

JPG250PS

200/250

1206A-E70TTAG3

UCDI274K

400

7.01

3800X1350X1950

JPG300PS

240/300

1506A-E88TAG5

HCI444D

480

8.8

4130X1400X2250

JPG350PS

280/350

2206C-E13TAG2

HCI444E

560

12.5

4300X1650X2500

JPG400PS

320/400

2206C-E13TAG3

HCI444F

640

12.5

4300X1650X2500

JPG450PS

360/450

2506C-E15TAG1

HCI544C

720

15.2

4500X1600X2500

JPG500PS

400/500

2506C-E15TAG2

HCI544C

800

15.2

4500X1600X2500

JPG600PS

480/600

2806C-E18TAG1A

HCI544E

960

18.1

4800X1800X2500

JPG650PS

520/650

2806A-E18TAG2

HCI544F

1050

18.1

4800X1800X2500

JPG750PS

600/750

4006-23TAG2A

LVI634B

1200

22.921

20FT

JPG800PS

640/800

4006-23TAG3A

LVI634C

1300

22.921

20FT

JPG1000PS

800/1000

4008TAG2A

LVI634E

1450

30.561

20FT

JPG1250PS

1000/1250

4012-46TWG2A

LVI634G

1500

45.842

40HQ

JPG1500PS

1200/1500

4012-46TAG2A

PI734C

1800

45.842

40HQ

JPG1700PS

1360/1700

4012-46TAG3A

PI734ES

1980

45.842

40HQ

JPG1850PS

1480/1850

4016TAG1A

PI734E

2220

61.1

40HQ

JPG2000PS

1600/2000

4016TAG2A

PI734F

2400

61.1

40HQ

JPG2200PS

1800/2200

4016-61TRG3

PI734H

2640

61.1

40HQ

JUSTPOWER PERKINS SERIES DIESEL GENERATORS 11KVA-1688KVA 60Hz/1800RPM

GENSET MODEL

POWER KW/KVA

Engine

Alternator

Fuel Capacity

(L)

Displacement

(L)

Dimension

(mm)

JPG11PS

9/11

403D-11G

PI044E

1.1

1730X850X1150

JPG15PS

12/15

403D-15G

PI044F

1.496

1730X850X1150

JPG24PS

19/24

404D-22G

PI144D

2.2

1950X900X1150

JPG33PS

26/33

404D-22TG

PI144E

2.2

1950X900X1150

JPG38PS

30/37.5

1103A-33G

PI144G

3.3

1950X900X1150

JPG76PS

61/76

1104A-44TG1

UCI224E

110

4.4

2600X1080X1450

JPG91PS

73/91

1104A-44TG2

UCI224F

130

4.4

2600X1080X1450

JPG115PS

92/115

1104C-44TAG2

UCI274C

160

4.4

2600X1080X1450

JPG153PS

122/153

1106A-70TG1

UCI274E

220

7.01

2850X1080X1650

JPG200PS

158/200

1106A-70TAG3

UCI274F

290

7.01

3400X1250X1750

JPG400PS

320/400

2206C-E13TAG2

HCI444ES

560

12.5

4300X1650X2500

JPG500PS

400/500

2506C-E15TAG1

HCI444F

720

15.2

4500X1600X2500

JPG750PS

600/750

4006-23TAG2A

HCI544E

1200

22.921

20FT

JPG825PS

660/825

4006-23TAG3A

HCI544F

1300

22.921

20FT

JPG1000PS

800/1000

4008TAG2

HCI634G

1450

30.561

20FT

JPG1250PS

1000/1250

4012-46TWG2A

HCI634J

1500

45.842

40HQ

JPG1500PS

1200/1500

4012-46TAG2A

LVI634G

1800

45.842

40HQ

JPG1688PS

1350/1688

4012-46TAG3A

PI734B

1980

45.842

40HQ

Our diesel generators can be configured to meet almost any demands.

Customization: Need something special?

We can customize any of our generators to better fit your needs. Tell us what you want or don't want. We can save you money and make sure that you are completely satisfied, we guarantee it.

Customized Product

Customization
You can tell us if you have any customization requirements
Controller	Deepsea, ComAp, Smartgen,ect.
Circuit Breaker	ABB,SCHNEIDER,CHINT,Etc.
Alternator	Stamford,Mecc Alte,Leroy Somer, Etc.
Type	Open/Silent/Super Silent/Compact/Weatherproof/Containerized
Fuel Tank	8 hours, 12 hours, 24 hours, 48 hours, base tank, external daily tank can be customized.
Movable supporting products	Moveable/Trailer Type Diesel Generator /Synchronization System Automatic Transfer Switch /Dummy Load Day Tank,Etc.

Contact us for customized details. We support products from different engine families, which are very popular and competitive.
